System And Components
318-5205 LINES GP-FUEL -SCRAPERS/N DBF130-UP
Group No: 318-5205
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4183 | 1 BOLT (M12X1.75X40-MM) | 1 | |
| 2042281 | 2 STRAP-CABLE | 2 | |
| 2006345 | 3 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 3471733 | 4 ANGLE | 1 | |
| 3510263 | 5 VALVE-BALL | 1 | |
| 3510266 | 6 VALVE-BALL | 1 | |
| 3524204 | 7 STRAP-CABLE | 12 | |
| 3529724 | 8 TUBE AS | 1 | |
| 3529725 | 9 TUBE AS | 1 | |
| 3529726 | 10 HOSE AS | 1 | |
| 3529735 | 11 HOSE AS | 1 | |
| 3668003 | 12 VALVE-CHECK | 1 | |
| 3670853 | 13 TUBE AS | 1 | |
| 3670854 | 14 TUBE AS | 1 | |
| 3713874 | 15 HOSE AS | 1 | |
| 3722033 | 16 HOSE AS | 1 | |
| 3722035 | 17 HOSE AS | 1 | |
| 3722036 | 18 HOSE AS | 1 | |
| 3728643 | 19 HOSE AS | 1 | |
| 3728652 | 20 HOSE AS | 1 | |
| 3728653 | 21 HOSE AS | 1 | |
| 3774889 | 22 HOSE AS | 1 | |
| 1572348 | 23 ELBOW | 1 | |
| 1578510 | 24 ADAPTER | 2 | |
| 1605083 | 25 CONNECTOR | 1 | |
| 1984778 | 26 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 2287090 | 27 SEAL-O-RING | 1 | |
| 2287091 | 28 SEAL-O-RING | 5 | |
| 2287092 | 29 SEAL-O-RING | 16 | |
| 2353583 | 30 CONNECTOR | 1 | |
| 2385080 | 31 SEAL-O-RING | 3 | |
| 2385082 | 32 SEAL-O-RING | 2 | |
| 2815934 | 33 ELBOW AS | 1 | |
| 6V9877 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2H3924 | 35 LOCKWASHER | 3 | |
| 2H3926 | 36 LOCKWASHER | 6 | |
| 2P1293 | 37 LOCKNUT (1-3/16-12-THD) | 4 | |
| 3196247 | 38 ADAPTER AS | 1 | |
| 6V1722 | ADAPTER | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3218632 | 39 CONNECTOR AS | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 2287091 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3309735 | 40 ELBOW AS | 1 | |
| 8T3491 | ELBOW | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 3524200 | 41 STRAP-CABLE | 14 | |
| 4D7388 | 42 CLIP | 1 | |
| 5P6994 | 43 CLIP | 11 | |
| 5P7464 | 44 CLIP (SLOT) | 2 | |
| 5P7465 | 45 CLIP (TAB) | 2 | |
| 5P7468 | 46 CLIP (SLOT) | 2 | |
| 5P7469 | 47 CLIP (TAB) | 2 | |
| 5P8444 | 48 GROMMET (37-MM ID) | 2 | |
| 6D4244 | 49 CLIP (LOOP) | 2 | |
| 6V6782 | 50 CLIP (SLOT) | 1 | |
| 6V6783 | 51 CLIP (TAB) | 1 | |
| 6V7359 | 52 GROMMET (25-MM ID, 37-MM OD) | 2 | |
| 6V8989 | 53 ELBOW | 1 | |
| 6V8990 | 54 ELBOW | 1 | |
| 6V8997 | 55 UNION | 2 | |
| 6V9170 | 56 NUT-BULKHEAD (1-14-THD) | 2 | |
| 6V9832 | 57 CAP (ORFS) | 1 | |
| 6W6672 | 58 SPACER (10.5X20X38-MM THK) | 1 | |
| 7G3833 | 59 CLIP (TAB) | 1 | |
| 7G3834 | 60 CLIP (SLOT) | 1 | |
| 7X7729 | 61 WASHER (11X25X3-MM THK) | 9 | |
| 8C3174 | 62 GROMMET | 1 | |
| 8T4121 | 63 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 8T4133 | 64 NUT (M10X1.5-THD) | 4 | |
| 8T4136 | 65 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4137 | 66 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4186 | 67 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4194 | 68 BOLT (M12X1.75X50-MM) | 3 | |
| 8T4195 | 69 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4223 | 70 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4244 | 71 NUT (M12X1.75-THD) | 4 | |
| 8T6466 | 72 BOLT (M10X1.5X60-MM) | 1 | |
| 8T4196 | 73 BOLT (M10X1.5X35-MM) | 1 | |
| 4S8002 | 74 CLAMP | 2 |
