System And Components
309-4750 BAFFLE GP-SOUND SUPPRESSIONS/N DBF1-UP
Group No: 309-4750
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 3286417 | 2 BAFFLE | 1 | |
| 3286418 | 3 BAFFLE | 1 | |
| 3605044 | 4 BAFFLE | 1 | |
| 3605043 | 5 BAFFLE | 1 | |
| 3426594 | 6 PLATE AS | 1 | |
| 3604941 | 7 COVER | 1 | |
| 3604953 | 8 COVER AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3604954 | 9 COVER (LH) | 1 | |
| 3604955 | 10 COVER (RH) | 1 | |
| 6V8513 | 11 WASHER-HARD (11X35X2.5-MM THK) | 16 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 12 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4133 | 14 NUT (M10X1.5-THD) | 6 | |
| 8T4136 | 15 BOLT (M10X1.5X25-MM) | 39 | |
| 8T4137 | 16 BOLT (M10X1.5X20-MM) | 14 | |
| 8T4222 | 17 WASHER-PLATED (11X32X2.5-MM THK) | 26 | |
| 8T7934 | 18 WASHER-HARD (11X21X5-MM THK) | 16 | |
| 3605049 | 19 BRACKET | 1 | |
| 3605037 | 20 BRACKET | 1 | |
| 8T4195 | 21 BOLT (M10X1.5X30-MM) | 4 |
