System And Components
309-4701 HOOD GP-TRACTOR -FRONTS/N DBF1-UP
Group No: 309-4701
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6R0552 | 1 WASHER (12.45X26X3.2-MM THK) | 32 | |
| 8T2444 | 2 STUD-BALL | 2 | |
| 1454746 | 3 STRAP AS | 1 | |
| 1071705 | 4 SPACER | 16 | |
| 3094770 | 5 PANEL GP-HOOD (FRONT) | 1 | |
| 3094771 | 6 SUPPORT GP-HOOD | 1 | |
| 3094772 | 7 GRILL GP (HOOD) | 1 | |
| 3193354 | GRILL AS-TOP | 1 | |
| 3193355 | GRILL AS-BOTTOM | 1 | |
| 3286466 | 8 BAFFLE | 1 | |
| 3286472 | 9 PLATE | 1 | |
| 3605030 | 10 SPRING AS-GAS | 1 | |
| 1293178 | 11 LOCKNUT (M6X1-THD) | 1 | |
| 1984777 | 12 WASHER-HARD (11X25X10-MM THK) | 34 | |
| 1984778 | 13 WASHER-HARD (13.5X30X12-MM THK) | 11 | |
| 5C7261 | 14 NUT (M8X1.25-THD) | 2 | |
| 5C9553 | 15 BOLT (M6X1X16-MM) | 1 | |
| 5P4116 | 16 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 5T7486 | 17 RETAINER-SPRING | 4 | |
| 7X0579 | 18 WASHER-HARD (8.8X25.5X2-MM THK) | 16 | |
| 7X7729 | 19 WASHER (11X25X3-MM THK) | 11 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 15 | |
| 8T4183 | 22 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4184 | 23 BOLT (M12X1.75X45-MM) | 7 | |
| 8T4195 | 24 BOLT (M10X1.5X30-MM) | 35 | |
| 8T6466 | 26 BOLT (M10X1.5X60-MM) | 5 | |
| 8T6870 | 27 BOLT (M8X1.25X70-MM) | 2 | |
| 8T7547 | 28 BOLT (M8X1.25X30-MM) | 16 | |
| 9X2038 | 29 WASHER (7X19X2-MM THK) | 2 |
