System And Components
312-1254 TRIM GP-CABS/N DBF1-UP
Group No: 312-1254
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1728591 | 1 NUT-CLIP (M6X1-THD) | 87 | |
| 7G4823 | 2 STRAP | 1 | |
| 7G4824 | 3 STRAP | 1 | |
| 8Y6388 | 5 LOUVER AS-VENT | 10 | |
| 8Y6967 | 6 LOUVER AS-VENT | 1 | |
| 1278891 | 7 HOLDER-CUP | 1 | |
| 1643765 | 8 RETAINER | 2 | |
| 1714046 | 9 LOUVER AS-VENT | 1 | |
| 2090746 | 10 STRAP | 1 | |
| 2126891 | 11 RETAINER | 2 | |
| 2326692 | 12 SCREW (M6X1X20-MM) | 2 | |
| 2402189 | 13 PLATE | 2 | |
| 4233272 | 14 FLOOR MAT AS | 1 | |
| 4478127 | 15 HEADLINER GP-CAB | 1 | |
| 3251076 | 16 COVER | 1 | |
| 3251079 | 17 COVER AS | 1 | |
| 3251080 | 18 PLENUM AS | 1 | |
| 3251081 | 19 COVER AS | 1 | |
| 3251084 | 20 COVER | 1 | |
| 3251087 | 21 COVER AS-CONTROL | 1 | |
| 3251088 | 22 COVER-FUSE | 1 | |
| 3251089 | 23 COVER-SEAT | 1 | |
| 3251090 | 24 COVER | 1 | |
| 3251091 | 25 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 3251092 | 26 DOOR-FUSE | 1 | |
| 3251093 | 27 DASH | 1 | |
| 3251097 | 28 COVER-DOOR | 1 | |
| 3346089 | 29 RECEPTACLE | 2 | |
| 3346090 | 30 STUD | 2 | |
| 3402569 | 31 PLENUM AS | 1 | |
| 3402570 | 32 COVER | 1 | |
| 3402571 | 33 COVER | 1 | |
| 3402572 | 34 COVER | 1 | |
| 3409398 | 35 COVER-FILTER | 1 | |
| 3424218 | 36 COVER | 1 | |
| 3424219 | 37 COVER AS | 1 | |
| 3433046 | 38 BRACKET | 1 | |
| 3521147 | 39 PLATE | 1 | |
| 3770648 | 40 COVER | 1 | |
| 7X0579 | 41 WASHER-HARD (8.8X25.5X2-MM THK) | 10 | |
| 1042091 | 42 SCREW-FLAT HEAD (6-20X0.5-IN) | 24 | |
| 2460435 | 43 SEAL (20-CM) | ||
| 3E8020 | 44 SCREW-TRUSS HEAD (M6X1X25-MM) | 8 | |
| 4S8264 | 45 RIVET-POP | 4 | |
| 8D6542 | 47 GROMMET | 1 | |
| 9D3767 | 48 PLUG-BUTTON | 2 | |
| 9X2038 | 49 WASHER (7X19X2-MM THK) | 88 | |
| 9X2045 | 50 SCREW-TRUSS HEAD (M6X1X20-MM) | 90 | |
| 1185619 | 51 SCREW-FLAT HEAD (6-20X1-IN) | 4 |
