Assembly
100%

348-0832 LINES GP-TURBOCHARGER AIRS/N MME1-UP; MYE104-UP

Group No: 348-0832
Part NumberPart NameQty
31770121 CLAMP-BAND2
44868822 TUBE AS-AIR1
34852223 BRACKET AS1
8T3612NUT-WELD (M8X1.25-THD)1
35000544 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)2
8T3612NUT-WELD (M8X1.25-THD)2
9R2672BOSS-THREADED (M10X1.5X20-MM)1
35890915 BRACKET AS1
5G4313SPACER (10.34X15.88X12-MM THK)1
8T3490NUT-WELD (M10X1.5-THD)1
36692866 TUBE AS-AIR1
36496327 ELBOW AS1
3649631ADAPTER-ELBOW1
2385080SEAL-O-RING1
36496288 ELBOW AS1
2147566SEAL-O-RING1
3649627ADAPTER-ELBOW1
36496269 ELBOW AS1
2147567SEAL-O-RING1
3649625ADAPTER-ELBOW1
337907310 CLIP2
345335011 CLIP1
7X772912 WASHER (11X25X3-MM THK)2
342213414 CLIP1
5P797016 NUT (M8X1.25-THD)1
8T413617 BOLT (M10X1.5X25-MM)2
6V521818 BOLT (M8X1.25X35-MM)1
6V583919 WASHER (11X21X2.5-MM THK)1
6V821220 BOLT (M10X1.5X16-MM)1
6V521721 BOLT (M8X1.25X20-MM)2
8T420022 BOLT (M8X1.25X16-MM)1
8T422423 WASHER-HARD (8.8X16X2-MM THK)1
290199324 STRAP-CABLE2
178333625 NUT-HEX FLANGE (M8X1.25-THD)3
9M197426 WASHER-HARD (8.8X16X2-MM THK)4
337417827 HOSE (57-CM)
330437428 SLEEVE (57-CM)
