System And Components
130-8914 LINES GP-FILTERS/N 99C3035-UP
Group No: 130-8914
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N8600 | 1 ADAPTER-BASE | 1 | |
| 2P4305 | 2 GASKET | 2 | |
| 2A4639 | 3 BOLT (3/8-16X1.625-IN) | 1 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 1A2029 | 5 BOLT (3/8-16X1.125-IN) | 8 | |
| 7C9010 | 6 SUPPORT-BASE | 1 | |
| 0S1571 | 7 BOLT (3/8-16X1.75-IN) | 5 | |
| 9S8752 | 8 NUT-FULL (3/8-16-THD) | 6 | |
| 1238188 | 9 BRACKET AS-FILTER | 1 | |
| 1A1460 | 10 BOLT (1/2-13X2-IN) | 1 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 12 | |
| 3P0650 | 13 SEAL-O-RING | 3 | |
| 1W1116 | 14 BODY-BYPASS | 1 | |
| 0L2070 | 15 BOLT (3/8-16X2.25-IN) | 1 | |
| 0617540 | 16 SEAL-O-RING | 4 | |
| 5P8068 | 17 SEAL-O-RING | 1 | |
| 1P4578 | 18 FLANGE-HALF | 8 | |
| 5P8244 | 19 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 6K3771 | 20 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 16 | |
| 5P9890 | 21 SEAL-O-RING | 2 | |
| 1190960 | 22 BRACKET | 1 | |
| 1254390 | 23 HOSE AS | 2 | |
| 0S1608 | 24 BOLT (3/8-16X3.75-IN) | 1 | |
| 0T0065 | 25 BOLT (3/8-16X3.5-IN) | 1 | |
| 6V5048 | 26 SEAL-O-RING | 1 | |
| 8C3446 | 27 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 8C3445 | 28 CAP-DUST | 1 | |
| 7D1649 | 29 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 1F7958 | 30 NUT-FULL (1/2-13-THD) | 1 | |
| 0S1595 | 31 BOLT (1/2-13X1.25-IN) | 1 | |
| 9M0853 | 32 PLUNGER-VALVE | 2 | |
| 9F6304 | 33 SPRING | 2 | |
| 4N0861 | 34 COVER | 1 | |
| 4N0865 | 35 GASKET | 1 | |
| 4N8410 | 36 TUBE-COOLER BYPASS | 1 | |
| 4N8770 | 37 ELBOW-COOLER OUTLET | 1 | |
| 9X6458 | 38 WASHER-HARD (10.2X22.5X3-MM THK) | 6 |
