System And Components
130-8918 LINES GP-AIRS/N 99C3035-UP
Group No: 130-8918
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1299416 | 1 GASKET | 1 | |
| 4W7062 | 2 ADAPTER | 1 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 5 | |
| 0S0509 | 4 BOLT (3/8-16X0.75-IN) | 2 | |
| 7W1944 | 5 RETAINER | 2 | |
| 8T6765 | 6 PLUG-PIPE (1/4-18-THD) | 1 | |
| 4W1073 | 7 TUBE-AIR | 1 | |
| 4L8337 | 8 SEAL-O-RING | 4 | |
| 5P9959 | 9 BOLT (5/16-18X0.5-IN) | 2 | |
| 9M1974 | 10 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1W6186 | 11 SHIELD AS | 1 | |
| 6V5044 | NUT-WELD (5/16-18-THD) | 2 | |
| 5P2755 | 12 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN) | 4 | |
| 8N2574 | 13 BRACKET | 1 | |
| 0S1594 | 14 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 8N0879 | 16 CLAMP | 4 | |
| 1215457 | 17 TUBE AS-EXHAUST | 1 | |
| 8N0878 | 18 CLAMP | 2 | |
| 8N4823 | 19 SUPPORT AS | 1 | |
| 1215455 | 20 TUBE AS-EXHAUST | 1 | |
| 0S1571 | 21 BOLT (3/8-16X1.75-IN) | 3 | |
| 0S1588 | 22 BOLT (3/8-16X1.25-IN) | 3 | |
| 5B7890 | 23 PLUG-PIPE | 2 | |
| 7E3205 | 24 MANIFOLD-INLET | 1 | |
| 1215459 | 25 TUBE AS-EXHAUST | 1 | |
| 1215461 | 26 TUBE AS-EXHAUST | 1 | |
| 4W4314 | 27 SUPPORT-TURBOCHARGER | 1 | |
| 0L2070 | 28 BOLT (3/8-16X2.25-IN) | 2 | |
| 0L1352 | 29 BOLT (3/8-16X3.25-IN) | 6 | |
| 9S8752 | 30 NUT-FULL (3/8-16-THD) | 5 | |
| 8N2258 | 31 SHIELD AS-BOTTOM | 1 | |
| 6V5044 | NUT-WELD (5/16-18-THD) | 7 | |
| 9M4136 | SPACER (0.438X0.75X0.5-IN THK) | 5 | |
| 1069408 | 32 SEAL-EXHAUST | 2 | |
| 1W0481 | 33 RING-EXHAUST SEAL | 2 | |
| 1125146 | 34 BRACKET | 1 |
