System And Components
129-5244 HOUSING GP-FLYWHEELS/N 99C1-UP
Group No: 129-5244
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C6948 | 1 HOUSING-FLYWHEEL | 1 | |
| 1617293 | 2 GASKET-CYLINDER | 1 | |
| 8T6765 | 3 PLUG-PIPE (1/4-18-THD) | 3 | |
| 3S0036 | 4 PLUG-CORE | 2 | |
| 8N7806 | 5 HOSE AS | 1 | |
| 1D4706 | 6 BOLT (3/8-16X6-IN) | 1 | |
| 8M9124 | 7 WASHER (10X22.5X8-MM THK) | 2 | |
| 7G2176 | 8 DAMPER-BOLT | 4 | |
| 8F8544 | 9 BOLT (3/8-16X6.25-IN) | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 1 | |
| 0T0573 | 11 BOLT (3/8-16X2.75-IN) | 6 | |
| 0L1143 | 12 BOLT (3/8-16X2.5-IN) | 1 | |
| 5F0304 | 13 PLUG (FLYWHEEL HOUSING) | 1 | |
| 2A1162 | 14 GASKET | 1 | |
| 0L2070 | 15 BOLT (3/8-16X2.25-IN) | 1 | |
| 2A1531 | 16 BOLT (1/2-13X6.5-IN) | 7 | |
| 2M0849 | 17 WASHER-HARD (13.5X25.5X5-MM THK) | 7 | |
| 1W3136 | 18 BAFFLE | 1 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 8L3282 | 20 CONNECTOR | 1 | |
| 0321268 | 21 CONNECTOR (90-DEG) | 1 | |
| 2306262 | 22 SEALANT |
