System And Components
Assembly
100%

131-3269 LINES GP-AIRS/N 80M5546-UP

Group No: 131-3269
Part NumberPart NameQty
7E32051 MANIFOLD-INLET1
5B78902 PLUG-PIPE2
8N08793 CLAMP4
12154594 TUBE AS-EXHAUST1
12154615 TUBE AS-EXHAUST1
8N08786 CLAMP2
1W04817 RING-EXHAUST SEAL2
10694088 SEAL-EXHAUST2
12154559 TUBE AS-EXHAUST1
121545710 TUBE AS-EXHAUST1
5M289411 WASHER-HARD (10.2X18.5X2.5-MM THK)12
8N225812 SHIELD AS-BOTTOM1
6V5044NUT-WELD (5/16-18-THD)7
9M4136SPACER (0.438X0.75X0.5-IN THK)5
1W618613 SHIELD AS1
6V5044NUT-WELD (5/16-18-THD)2
9M197414 WASHER-HARD (8.8X16X2-MM THK)2
5P995915 BOLT (5/16-18X0.5-IN)2
8N257416 BRACKET1
0S159417 BOLT (3/8-16X1-IN)3
129941718 GASKET1
1W538019 ADAPTER1
7W591920 ELBOW-OUTLET1
4L833721 SEAL-O-RING2
7W194422 RETAINER1
0S050923 BOLT (3/8-16X0.75-IN)2
5S118824 SEAL-O-RING2
5P275525 BOLT-HIGH TEMPERATURE (3/8-16X2.75-IN)4
8T676526 PLUG-PIPE (1/4-18-THD)2
3B191527 BOLT (3/8-16X1.375-IN)5
7W314528 PLATE1
2W962429 SUPPORT-TURBOCHARGER1
0S158830 BOLT (3/8-16X1.25-IN)5
7W564831 GASKET1
0S160832 BOLT (3/8-16X3.75-IN)2
0L076533 STUD (3/8-16X1.75-IN)1
9S875234 NUT-FULL (3/8-16-THD)1
183294835 BRACKET1
0L135236 BOLT (3/8-16X3.25-IN)3
1W630837 PLATE1
067984638 SPACER (PIPE)3
8S794139 PIPE2
