System And Components
109-9010 CYLINDER BLOCK GPS/N 80M1-UP
Group No: 109-9010
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N1650 | 2 DOWEL | 4 | |
| 8T6763 | 3 PLUG-PIPE (1/4-18-THD) | 4 | |
| 1261375 | 4 CYLINDER BLOCK AS | 1 | |
| 8T6757 | 5 PLUG-PIPE | 5 | |
| 2253101 | 6 GASKET-PLATE | 2 | |
| 2253100 | 7 PLATE-SPACER | 2 | |
| 7C9614 | 8 PLUG-TAPERLOCK (1-5/8-12-THD) | 3 | |
| 4N0683 | 9 DOWEL | 4 | |
| 1018917 | 10 STUD-TAPERLOCK (3/8-16X4.5-IN) | 26 | |
| 3B0645 | 11 PLUG-CUP (32.08-MM OD) | 1 | |
| 6L4428 | 12 STUD-TAPERLOCK (3/8-16X4.01-IN) | 3 | |
| 5P8356 | 14 SEAL-O-RING | 4 | |
| 3S6605 | 15 PLUG-CUP | 2 | |
| 7C7407 | 16 STUD | 1 | |
| 1010523 | INSERT-LINER SEAT (5.21-MM THK) | ||
| 1010524 | INSERT-LINER SEAT (5.16-MM THK) | ||
| 1010525 | INSERT-LINER SEAT (5.26-MM THK) | ||
| 6I4361 | INSERT-LINER SEAT (0.772-MM THK) | ||
| 9Y3368 | INSERT-LINER SEAT (0.822-MM THK) | ||
| 6I4362 | INSERT-LINER SEAT (0.872-MM THK) | ||
| 6I4363 | INSERT-LINER SEAT (1.555-MM THK) | ||
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | ||
| 6I4365 | INSERT-LINER SEAT (2.66-MM THK) | ||
| 6I4364 | INSERT-LINER SEAT (1.655-MM THK) | ||
| 5N0093 | INSERT-LINER SEAT (2.71-MM THK) | ||
| 6I4366 | INSERT-LINER SEAT (2.76-MM THK) |
