System And Components
1N-3348 LINES GP-ENGINE OIL FILTERS/N 80M1-UP
Group No: 1N-3348
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N8600 | 1 ADAPTER-BASE | 1 | |
| 2P4305 | 2 GASKET | 2 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 4 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 0S1591 | 5 BOLT (3/8-16X1.5-IN) | 6 | |
| 7C5011 | 6 SUPPORT-OIL FILTER | 1 | |
| 7C9010 | 7 SUPPORT-BASE | 1 | |
| 0S1571 | 8 BOLT (3/8-16X1.75-IN) | 2 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 4 | |
| 1A1460 | 10 BOLT (1/2-13X2-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9F6304 | 11 SPRING | 2 | |
| 9M0853 | 12 PLUNGER-VALVE | 2 | |
| 4N0861 | 13 COVER | 1 | |
| 4N0865 | GASKET | 1 | |
| 0S1608 | 14 BOLT (3/8-16X3.75-IN) | 1 | |
| 4N8770 | 15 ELBOW-COOLER OUTLET | 1 | |
| 0T0065 | BOLT (3/8-16X3.5-IN) | 1 | |
| 4N8411 | 16 TUBE-COOLER BYPASS | 1 | |
| 1142687 | 17 SEAL-O-RING | 2 | |
| 1N2989 | 18 BRACKET-FILTER | 1 | |
| 0L2070 | 19 BOLT (3/8-16X2.25-IN) | 3 | |
| 1090076 | 20 SEAL-O-RING | 3 | |
| 1W1116 | 21 BODY-BYPASS | 1 | |
| 0S1594 | 22 BOLT (3/8-16X1-IN) | 10 | |
| 1090078 | 23 SEAL-O-RING | 1 | |
| 6K3771 | 24 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 16 | |
| 5P8244 | 25 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 7E9227 | 26 HOSE AS | 1 | |
| 1P4578 | 27 FLANGE-HALF | 8 | |
| 1187214 | 28 SEAL-O-RING | 4 | |
| 0308194 | 29 CONNECTOR | 1 | |
| 6V4589 | SEAL-O-RING | 1 | |
| 8N7806 | 30 HOSE AS | 1 | |
| 0321268 | 31 CONNECTOR (90-DEG) | 1 | |
| 7C9452 | 32 HOSE AS | 1 | |
| 9X7378 | 33 SEAL-O-RING | 1 | |
| 8C3446 | 34 VALVE-SAMPLING | 1 | |
| 8C3445 | 35 CAP-DUST | 1 |
