System And Components
235-3987 AIR COMPRESSOR GPS/N TX71-UP
Group No: 235-3987
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N9679 | 1 GOVERNOR AS-AIR COMPRESSOR | 1 | |
| 2S2923 | COVER AS | 1 | |
| 2K8198 | SEAL-O-RING | 1 | |
| 4P5106 | 2 BRACKET | 1 | |
| 4P5389 | 3 VALVE AS-RELIEF (AIR COMPRESSOR GOVERNOR) | 1 | |
| 6L1883 | 4 GASKET (GOVERNOR) | 1 | |
| 8T6757 | 5 PLUG-PIPE | 3 | |
| 1359819 | 6 SEAL-INTEGRAL | 1 | |
| 3899576 | 7 AIR COMPRESSOR GP | 1 | |
| 2001196 | 8 HOSE AS | 1 | |
| 8T4195 | 9 BOLT (M10X1.5X30-MM) | 2 | |
| 2N1287 | 10 ELBOW-FLARED | 1 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 4M6424 | 12 BOLT (5/16-18X3-IN) | 2 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V4248 | 14 BOLT (M10X1.5X25-MM) | 3 | |
| 6D3479 | 15 CLIP (LOOP) | 1 | |
| 6V5696 | 16 BOLT (M12X1.75X80-MM) | 2 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 4391826 | 18 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 9M0402 | KIT-GOVERNOR OVERHAUL (AIR COMPRESSOR) | 1 |
