System And Components
122-1898 LINES GP-ENGINE OIL FILTERS/N 80M1-UP
Group No: 122-1898
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C5011 | 1 SUPPORT-OIL FILTER | 1 | |
| 0S1591 | 2 BOLT (3/8-16X1.5-IN) | 6 | |
| 2P4305 | 3 GASKET | 2 | |
| 4N8600 | 4 ADAPTER-BASE | 1 | |
| 1A2029 | 5 BOLT (3/8-16X1.125-IN) | 4 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 7C9010 | 7 SUPPORT-BASE | 1 | |
| 0S1571 | 8 BOLT (3/8-16X1.75-IN) | 4 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 4 | |
| 1187214 | 10 SEAL-O-RING | 4 | |
| 0S1608 | 11 BOLT (3/8-16X3.75-IN) | 1 | |
| 1P4578 | 12 FLANGE-HALF | 8 | |
| 4N8770 | 13 ELBOW-COOLER OUTLET | 1 | |
| 4N8411 | 14 TUBE-COOLER BYPASS | 1 | |
| 8C3446 | 15 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 8C3445 | 16 CAP-DUST (ENGINE OIL FILTER LINES) | 1 | |
| 0L2070 | 17 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1594 | 18 BOLT (3/8-16X1-IN) | 10 | |
| 1090076 | 19 SEAL-O-RING | 3 | |
| 1W1116 | 20 BODY-BYPASS | 1 | |
| 1090078 | 21 SEAL-O-RING | 1 | |
| 6K3771 | 22 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 16 | |
| 0T0065 | 23 BOLT (3/8-16X3.5-IN) | 1 | |
| 9X7378 | 24 SEAL-O-RING | 1 | |
| 1P1367 | 25 PLUNGER (RELIEF VALVE) | 2 | |
| 9F6304 | 26 SPRING | 2 | |
| 4N0861 | 27 COVER | 1 | |
| 4N0865 | 28 GASKET | 1 | |
| 7E9227 | 29 HOSE AS | 1 | |
| 7C9452 | 30 HOSE AS | 1 | |
| 1142687 | 31 SEAL-O-RING | 2 | |
| 5P8244 | 32 WASHER-HARD (12X22.5X2.5-MM THK) | 16 |
