System And Components
3N-9582 BELT TIGHTENER GPPART OF 321-6317, 333-1670 ENGINE AR
Group No: 3N-9582
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D8822 | 1 STUD-TAPERLOCK (5/8-11X2.36-IN) | 1 | |
| 1A5964 | 2 BOLT (3/8-16X4.5-IN) | 7 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 7N6821 | 4 COVER | 1 | |
| 0S1594 | 5 BOLT (3/8-16X1-IN) | 9 | |
| 0L1351 | 6 BOLT (3/8-16X0.875-IN) | 2 | |
| 9F2247 | 7 PLUG-PIPE (1/8-27-THD) | 1 | |
| 7W5733 | 8 GASKET | 1 | |
| 5M1932 | 9 STUD-TAPERLOCK (1/2-13X2.17-IN) | 1 | |
| 9N0316 | 10 BRACKET-PULLEY | 1 | |
| 9N0311 | 11 SPACER-BEARING | 1 | |
| 9N1012 | 12 SPACER-BEARING (1.438X1.75X1-IN THK) | 1 | |
| 8H9789 | 13 BALL BEARING | 2 | |
| 2F6262 | 14 WASHER | 1 | |
| 6U1989 | 15 VALVE-RELIEF (BELT TIGHTNER) | 1 | |
| 7H7954 | 16 BOLT (3/8-16X2.125-IN) | 1 | |
| 1W6134 | 17 COVER | 1 | |
| 5F3092 | 18 SEAL-O-RING | 1 | |
| 3N9583 | 19 PULLEY-TIGHTENER | 1 | |
| 3B8485 | 20 ELBOW (BELT TIGHTNER) | 1 | |
| 5S2106 | 21 SEAL-LIP TYPE | 1 | |
| 4N4526 | 22 COVER | 1 | |
| 2P2720 | 23 GASKET | 1 | |
| 0349362 | 24 TUBE | 1 | |
| 2D4534 | 25 BOLT-SOCKET HEAD (3/8-16X1-IN) | 1 | |
| 0S1613 | 26 BOLT (1/4-20X0.375-IN) | 1 | |
| 5P0537 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 4K0367 | 28 NUT-FULL (5/8-11-THD) | 1 | |
| 2S7593 | 29 WASHER-HARD (17X35X5-MM THK) | 1 | |
| 1F7958 | 30 NUT-FULL (1/2-13-THD) | 1 | |
| 2M0849 | 31 WASHER-HARD (13.5X25.5X5-MM THK) | 1 |
