System And Components
115-2373 HOUSING GP-ENGINE BRAKEREAR
Group No: 115-2373
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1436594 | 1 CLIP-HARNESS | 1 | |
| 1Q9550 | 2 SCREW-DRIVE | 1 | |
| 1631614 | 3 COVER | 2 | |
| 2U1481 | 4 PISTON | 3 | |
| 2U1526 | 5 SPRING-FLAT | 3 | |
| 1Q9551 | 6 SCREW-BUTTON HEAD (1/2-20X3/8-IN) | 5 | |
| 2U1522 | 7 SCREW | 3 | |
| 9L7712 | 8 NUT (3/8-24-THD) | 3 | |
| 2U1468 | 9 SPRING | 3 | |
| 2U1469 | 10 SPRING | 3 | |
| 2U1470 | 11 RETAINER-SPRING | 3 | |
| 1Q9552 | 12 PISTON | 3 | |
| 2U1471 | 13 RING-RETAINING | 3 | |
| 2U1467 | 14 SPRING | 3 | |
| 1631536 | 15 SOLENOID | 1 | |
| 2U1493 | 16 SEAL | 1 | |
| 2U1492 | 17 SEAL | 1 | |
| 1436642 | 18 SEAL | 1 | |
| 1028780 | 19 SPOOL AS-VALVE | 3 | |
| 2U1488 | 20 SPRING | 3 | |
| 2U1487 | 21 SPRING | 3 |
