System And Components
222-8153 LINES GP-FUELS/N 6PR1-UP; 7KR1-UP
Group No: 222-8153
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3G4005 | 1 LINK | 3 | |
| 5P4961 | 2 CLAMP-HOSE | 1 | |
| 1545650 | 3 HOSE AS | 1 | |
| 1897236 | 4 HOSE AS | 1 | |
| 2573587 | 5 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2619259 | 6 HOSE AS | 1 | |
| 0S1588 | 7 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1621 | 8 BOLT (1/2-13X1-IN) | 1 | |
| 1488318 | 9 CONNECTOR AS | 2 | |
| 6V8634 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488364 | 10 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488371 | 11 ELBOW AS | 1 | |
| 8C8988 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488378 | 12 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 3S8664 | 13 CLIP | 2 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 3 | |
| 5K5338 | 15 CLIP (LOOP) | 3 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P8245 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V8397 | 18 SEAL-O-RING | 1 | |
| 6V8556 | 19 NUT (1-3/16-12-THD) | 1 | |
| 6V8801 | 20 NUT (3/8-16-THD) | 3 | |
| 6V8941 | 21 REDUCER | 1 | |
| 8T4896 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P1442 | 23 HOSE (24-CM) |
