System And Components
226-3947 HOOD GP-SCRAPERS/N 6PR1-UP; 7KR1-UP
Group No: 226-3947
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P7115 | 1 GROMMET AS | 8 | |
| 6G9943 | 2 BOLT-SPECIAL | 8 | |
| 2263948 | 3 PLATE AS | 1 | |
| 5C3162 | BLOCK | 3 | |
| 2263949 | 4 SUPPORT AS | 1 | |
| 8J1196 | LUG (3/8-16-THD) | 1 | |
| 4D6293 | BOSS (3/8-16X1.31-IN) | 3 | |
| 2263950 | 5 PLATE AS | 1 | |
| 5C3162 | BLOCK | 3 | |
| 1165351 | RIVET | 19 | |
| 2584560 | 6 HANDRAIL AS | 2 | |
| 2731053 | 7 COVER | 1 | |
| 2731054 | 8 PLATE AS | 1 | |
| 2731055 | 9 SUPPORT AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 8T5911 | NUT-WELD (1/2-13-THD) | 2 | |
| 2775744 | 10 BAR | 1 | |
| 4D7388 | 11 CLIP | 3 | |
| 4L6454 | 12 BOLT (3/8-16X1-IN) | 3 | |
| 5P1076 | 13 WASHER-HARD (13.5X30X4-MM THK) | 4 | |
| 5P2566 | 14 BOLT (1/2-13X1.5-IN) | 4 | |
| 1984778 | 15 WASHER-HARD (13.5X30X12-MM THK) | 6 | |
| 8S0023 | 16 CLIP (SLOT) | 2 | |
| 8T8917 | 17 BOLT (1/2-13X1.25-IN) | 2 | |
| 6V8189 | 18 NUT (5/16-18-THD) | 8 | |
| 7X0772 | 19 WASHER-HARD (10.2X25.5X2.5-MM THK) | 8 | |
| 8C9987 | 20 WASHER (8.3X28X2.5-MM THK) | 8 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 7 | |
| 4L9337 | 22 BOLT (3/8-16X1.5-IN) | 8 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 4 | |
| 6V8188 | 24 NUT (1/2-13-THD) | 2 | |
| 8T9389 | 25 BOLT (1/2-13X2.75-IN) | 2 | |
| 1984777 | 26 WASHER-HARD (11X25X10-MM THK) | 8 | |
| 8T4994 | 27 WASHER-HARD (20X36.5X3.5-MM THK) | 4 | |
| 8T9398 | 28 BOLT (3/4-10X1.75-IN) | 4 | |
| 8S0024 | 29 CLIP (TAB) | 2 |
