System And Components
186-5202 LINES GP-TURBOCHARGER OILS/N 6NC18891-33658; 10Z41091-UP
Group No: 186-5202
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C8644 | 1 TUBE AS-SUPPLY | 1 | |
| 7C8643 | 2 TUBE AS-DRAIN | 1 | |
| 1P1255 | 3 GASKET-OIL DRAIN | 1 | |
| 1A2029 | 4 BOLT (3/8-16X1.125-IN) | 5 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 3J7354 | 6 SEAL-O-RING | 1 | |
| 8H9788 | 7 GASKET | 1 | |
| 4B3388 | 8 BOLT (5/16-18X1.125-IN) | 1 | |
| 1B2790 | 9 BOLT (5/16-18X1.375-IN) | 1 | |
| 0S1617 | 10 BOLT (5/16-18X0.75-IN) | 1 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5S0003 | 12 NUT (5/16-18-THD) | 1 | |
| 6N6033 | 13 CLIP | 2 | |
| 3K0360 | 14 SEAL-O-RING | 2 | |
| 1184728 | 15 ELBOW | 1 | |
| 9M4849 | 16 SEAL-O-RING | 1 | |
| 5M6213 | 17 PLUG-PIPE (1/4-18-THD) | 1 | |
| 8M5248 | 18 SEAL-O-RING | 2 | |
| 8M5253 | 19 SEAL-O-RING | 1 | |
| 9S4185 | 20 PLUG (3/4-16-THD) | 1 | |
| 4W1512 | 21 SUPPORT AS-PUMP | 1 | |
| 5H4279 | 21A PLUG-CUP | 1 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 8N1149 | 22 ELBOW | 1 | |
| 4M6480 | 23 GASKET | 1 | |
| 0L2070 | 24 BOLT (3/8-16X2.25-IN) | 1 | |
| 9S8002 | 25 PLUG (7/16-20-THD) | 1 | |
| 5L1719 | 26 STUD-TAPERLOCK | 1 |
