System And Components
284-7031 AIR COMPRESSOR GPS/N 99C9976-UP
Group No: 284-7031
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4N6004 | 1 TUBE | 1 | |
| 4N7378 | 2 AIR COMPRESSOR GP | 1 | |
| 4N9680 | 3 GOVERNOR GP-AIR COMPRESSOR | 1 | |
| 5F5434 | 4 VALVE AS-VENT (GOVERNOR, AIR COMPRESSOR) | 1 | |
| 6L1883 | 5 GASKET (GOVERNOR) | 1 | |
| 6N0634 | 6 GASKET-COVER | 1 | |
| 8F4994 | 7 SEAL-O-RING | 2 | |
| 9L6938 | 8 COVER | 1 | |
| 9M0378 | 9 BOLT (5/16-18X2.87-IN) | 2 | |
| 1293948 | 10 SEAL-INTEGRAL | 1 | |
| 0L1351 | 11 BOLT (3/8-16X0.875-IN) | 5 | |
| 1F7958 | 12 NUT-FULL (1/2-13-THD) | 3 | |
| 1L4076 | 13 STUD (1/2-13X3.54-IN) | 2 | |
| 2H5330 | 14 BOLT (3/8-16X2.88-IN) | 1 | |
| 2M0849 | 15 WASHER-HARD (13.5X25.5X5-MM THK) | 3 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T6757 | 17 PLUG-PIPE | 5 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 |
