System And Components
234-5985 CYLINDER HEAD GPS/N BET12057-UP
Group No: 234-5985
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2239250 | 1 CYLINDER HEAD GP | 1 | |
| 2245122 | 2 GASKET (CYLINDER HEAD) | 1 | |
| 3E6772 | 3 SEAL (WATER) | 24 | |
| 6I4025 | 4 FASTENER GP-CYLINDER HEAD | 16 | |
| 5H1504 | WASHER-HARD (20X33.5X5-MM THK) | 1 | |
| 1241855 | BOLT-12 POINT HEAD (3/4-16X7.638-IN) | 1 | |
| 1948124 | 5 SLEEVE AS (EXHAUST PORT) | 6 | |
| 1065673 | 6 FASTENER GP-CYLINDER HEAD | 10 | |
| 5H1504 | WASHER-HARD (20X33.5X5-MM THK) | 1 | |
| 1241854 | BOLT-12 POINT HEAD (3/4-16X8.5-IN) | 1 | |
| 5P0840 | 7 SEAL-O-RING | 1 | |
| 2416186 | 8 ELBOW | 1 | |
| 1946724 | 9 SENSOR GP-PRESSURE (TURBOCHARGER OUTLET) | 1 | |
| 2147566 | 10 SEAL-O-RING | 1 | |
| 1078618 | 11 SENSOR GP-TEMPERATURE (INLET AIR) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1124550 | SLEEVE (34-CM) | ||
| 2385080 | 12 SEAL-O-RING | 1 | |
| 1005725 | 13 STUD (3/8-16X1.25-IN) | 1 | |
| 8T4896 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 2147568 | 16 SEAL-O-RING | 1 | |
| 1833407 | 17 PLUG AS | 3 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 |
