System And Components
137-5921 GEAR GP-FRONTS/N BET12057-UP
Group No: 137-5921
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1571 | 1 BOLT (3/8-16X1.75-IN) | 1 | |
| 2J3118 | 2 BOLT-LOCKING (3/8-16X1.25-IN) | 5 | |
| 5P4142 | 3 BOLT-LOCKING (3/8-16X1.5-IN) | 2 | |
| 1B8705 | 4 KEY-WOODRUFF | 1 | |
| 1P7346 | 5 WASHER-HARD (10.2X35X6-MM THK) | 1 | |
| 1261756 | 6 BOLT-LOCKING (5/16-18X0.875-IN) | 10 | |
| 1129217 | 7 PLATE-THRUST | 1 | |
| 1304701 | 8 GEAR AS (56-TEETH) | 1 | |
| 1304698 | BUSHING | 1 | |
| 1515966 | 9 SHAFT AS-STUB | 1 | |
| 6I3623 | DOWEL | 1 | |
| 6I3624 | 10 PLATE-THRUST | 2 | |
| 6I3625 | 11 GEAR AS (71-TEETH) | 1 | |
| 1018468 | BUSHING | 1 | |
| 1282659 | 12 GEAR AS (105, 63-TEETH) | 1 | |
| 6I4581 | GEAR (105-TEETH) | 1 | |
| 6I4582 | GEAR (63-TEETH) | 1 | |
| 1317123 | BUSHING | 1 | |
| 1B8705 | KEY-WOODRUFF | 1 | |
| 2483008 | 13 SHAFT-STUB | 1 | |
| 1583416 | 14 SHAFT-STUB | 1 | |
| 0313185 | 15 BOLT-12 POINT HEAD (5/8-11X3-IN) | 6 | |
| 7E5661 | 16 GEAR-OIL PUMP DRIVE (69-TEETH) | 1 | |
| 9S8752 | 17 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6458 | 18 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 1178801 | 19 SEAL-O-RING | 1 | |
| 5E8771 | 20 SEAL-O-RING | 1 | |
| 1178557 | 21 PLATE-SEAL | 1 | |
| 1288853 | 22 ADAPTER AS | 1 | |
| 6V3677 | DOWEL | 1 | |
| 1025861 | 23 PLATE-THRUST | 1 | |
| 1070583 | 24 BOLT-LOCKING (1/4-20X0.87-IN) | 3 | |
| 2042114 | 25 GEAR GP-CAMSHAFT (96-TEETH) | 1 |
