System And Components
7E-4697 CYLINDER BLOCK GPPART OF 321-6313, 321-6314, 321-6315, 321-6316 ENGINE AR
Group No: 7E-4697
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E3632 | 1 JET AS-PISTON COOLING | 6 | |
| 9F2247 | 2 PLUG-PIPE (1/8-27-THD) | 3 | |
| 7M7410 | 3 PLUG-PIPE | 1 | |
| 9S8009 | 4 PLUG-O-RING | 1 | |
| 7H3171 | 5 PLUG-PIPE | 3 | |
| 1S9540 | 6 DOWEL | 2 | |
| 3S5496 | 7 SEAL-O-RING | 2 | |
| 3J5389 | 8 PLUG (EXTERNAL) | 1 | |
| 0307571 | 9 BOLT (3/8-16X1-IN) | 4 | |
| 4W8585 | 10 COVER | 1 | |
| 7W6081 | 11 GASKET | 1 | |
| 2M6471 | 12 PLUG-CUP | 2 | |
| 4N0683 | 13 DOWEL | 4 | |
| 4N1650 | 14 DOWEL | 2 | |
| 2W8601 | 15 PLATE-SPACER | 1 | |
| 7C3037 | 16 GASKET-PLATE | 1 | |
| 8S9094 | 17 PLUG-ORIFICE | 1 | |
| 9S4190 | 18 PLUG-O-RING (7/8-14-THD) | 2 | |
| 2M9780 | 19 SEAL-O-RING | 2 | |
| 3J5390 | 20 PLUG (3/8-18-THD) | 6 | |
| 7E6479 | 21 BOLT-SPECIAL (OIL JET) | 6 | |
| 4N0685 | 22 BUSHING (1-IN WIDE) | 6 | |
| 4N6658 | 23 BUSHING (1.3-IN WIDE) | 1 | |
| 5M6214 | 24 PLUG (1/8-27 PTF) | 1 | |
| 8N9266 | 25 CYLINDER BLOCK AS | 1 | |
| 9L5854 | 26 BAND-FILLER (130.2-MM ID) | 6 | |
| 6V5121 | 27 SEAL-O-RING | 18 | |
| 3P1323 | 28 BOLT-BEARING CAP (7/8-14X7.75-IN) | 14 | |
| 9H1031 | 29 WASHER-HARD (24X41.5X6-MM THK) | 14 | |
| 7W3550 | 30 LINER-CYLINDER BLOCK | 6 | |
| 4N5857 | 31 CAP-CRANKSHAFT BEARING | 7 | |
| 4K1388 | 32 SEAL-O-RING | 1 |
