System And Components
4N-2293 LINES GP-ENGINE OILPART OF 321-6313, 321-6314, 321-6315, 321-6316 ENGINE AR
Group No: 4N-2293
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 12 | |
| 8C5230 | 2 SEAL-O-RING | 2 | |
| 4N0933 | 3 GASKET | 1 | |
| 1W6135 | 4 TUBE AS | 1 | |
| 1W6137 | 5 TUBE AS | 1 | |
| 3929208 | 6 PLUNGER-VALVE (RELIEF) | 1 | |
| 4N8150 | 7 SPRING | 1 | |
| 2P3761 | 8 COVER | 1 | |
| 4N1215 | 9 BODY-COOLER BYPASS (ENGINE OIL) | 1 | |
| 2235814 | BODY-COOLER BYPASS (ENGINE OIL) | 1 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 2 | |
| 1135304 | 11 SEAL-O-RING | 2 | |
| 2K4973 | 12 LOCKNUT (3/8-16-THD) | 2 | |
| 5P8068 | 13 SEAL-O-RING | 3 | |
| 5P5846 | 14 SEAL-O-RING | 1 | |
| 9X6458 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 1152370 | 16 TUBE AS-SUCTION | 1 | |
| 8T6765 | 17 PLUG-PIPE (1/4-18-THD) | 2 | |
| 3218642 | PLUG AS | 2 | |
| 9S8003 | PLUG (1/2-20-THD) | 1 | |
| 2147567 | SEAL-O-RING | 1 | |
| 0L1351 | 18 BOLT (3/8-16X0.875-IN) | 3 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 1152353 | 20 BRACKET-TUBE | 1 | |
| 4N0995 | 21 TUBE AS | 1 | |
| 0S1591 | 22 BOLT (3/8-16X1.5-IN) | 2 | |
| 4N1216 | 23 TUBE-COOLER BYPASS (ENGINE OIL) | 1 | |
| 4N0826 | 24 ELBOW | 1 | |
| 2P3760 | 25 GASKET | 1 | |
| 2N3350 | 26 SEAL-O-RING | 2 |
