System And Components
7N-8187 CARTRIDGE GP-TURBOCHARGERS/N 99C9902-UP
Group No: 7N-8187
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N7962 | 1 PLATE AS-BACKING | 1 | |
| 7W0130 | BEARING-THRUST | 1 | |
| 7W0131 | STUD-DRIVE | 3 | |
| 1P1120 | 2 RING-SEAL | 1 | |
| 7E9493 | 3 HOUSING AS-BEARING | 1 | |
| 4M6646 | PIN-GROOVED | 2 | |
| 7W2368 | RING-SEAL | 1 | |
| 9N2043 | 4 WHEEL & SHAFT AS | 1 | |
| 7N3759 | 5 RING-PISTON | 1 | |
| 9M8915 | 6 RING-RETAINING | 3 | |
| 6N5004 | 7 BEARING-THRUST | 1 | |
| 9M8911 | 8 COLLAR-THRUST | 1 | |
| 9M8919 | 9 RING-SEAL | 2 | |
| 1294863 | 10 WHEEL-COMPRESSOR | 1 | |
| 1S1770 | 11 LOCKNUT-TURBOCHARGER | 1 | |
| 9N2046 | 12 SPACER-THRUST | 1 | |
| 0S1616 | 13 BOLT (1/4-20X1-IN) | 4 | |
| 2F0808 | 14 SCREW (6X0.25-IN) | 2 | |
| 2W0715 | KIT-CARTRIDGE (TURBOCHARGER) | 1 | |
| 9N2041 | KIT-BEARING | 1 | |
| 7N3193 | KIT-BEARING (0.13-MM OS,0.13-MM US) | 1 | |
| 7N3194 | KIT-BEARING (0.25-MM OS, 0.25-MM US) | 1 | |
| 8N4158 | KIT-BEARING (0.13-MM OS) | 1 | |
| 8N4159 | KIT-BEARING (0.13-MM US) | 1 | |
| 8N4157 | KIT-BEARING (0.25-MM OS) | 1 | |
| 8N4160 | KIT-BEARING (0.25-MM US) | 1 | |
| 7C7446 | KIT-BEARING (0.51-MM OS) | 1 | |
| 7C7447 | KIT-BEARING (0.51-MM OS, 0.25-MM US) | 1 |
