System And Components
478-6235 DRIVE GP-ACCESSORYS/N AGC1-UP; 3PR1-UP
Group No: 478-6235
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1295096 | 1 PULLEY-ALTERNATOR (8-GROOVE) | 1 | |
| 2614354 | 2 BELT TENSIONER GP | 1 | |
| 4720559 | 3 COMPRESSOR GP-REFRIGERANT | 1 | |
| 3429964 | 4 SPACER (6.8X20X50.8-MM THK) | 1 | |
| 3429969 | 5 INSERT | 5 | |
| 5613002 | 6 ALTERNATOR GP-CHARGING (24-VOLT, 150-AMPERE) | 1 | |
| 5901363 | 7 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 5041783 | 8 GUARD | 1 | |
| 5041784 | 9 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 5067124 | 10 PLATE | 1 | |
| 1984776 | 11 WASHER-HARD (8.8X20X8-MM THK) | 5 | |
| 3055385 | 12 BOLT (M8X1.25X50-MM) | 5 | |
| 4571045 | 13 NUT (3/8-16-THD) | 3 | |
| 7X2538 | 14 BOLT (M8X1.25X100-MM) | 4 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4198 | 17 BOLT (M10X1.5X100-MM) | 4 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 8T7547 | 19 BOLT (M8X1.25X30-MM) | 1 |
