System And Components
266-2367 DRIVE GP-FANS/N AGC1-UP; 3PR1-UP
Group No: 266-2367
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4617 | 1 PIN-COTTER | 4 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3H0120 | 3 ELBOW | 1 | |
| 4B4550 | 4 FITTING-PRESSURE RELIEF (1/8-27 PTF) | 1 | |
| 7N5959 | 5 SPRING | 2 | |
| 2662362 | 6 BRACKET AS-FAN | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 1W5075 | SHAFT-FAN | 1 | |
| 2D6642 | BALL | 1 | |
| 8H9189 | DOWEL | 1 | |
| 2662365 | 7 BELT TIGHTENER GP | 1 | |
| 8N6710 | 8 V-BELT SET (INCLUDES 4-BELTS)(FAN) | 1 | |
| 2662415 | 9 PULLEY | 1 | |
| 2662508 | 10 ADAPTER-FAN | 1 | |
| 2862215 | 11 HOSE AS | 1 | |
| 2862216 | 12 BRACKET AS | 1 | |
| 0S0175 | 13 PIN-CLEVIS | 4 | |
| 5S7383 | 14 BOLT (3/8-16X1.75-IN) | 6 | |
| 1D4624 | 15 BOLT (3/4-10X9-IN) | 1 | |
| 1N4036 | 16 PULLEY-FAN DRIVE | 1 | |
| 1T0210 | 17 BALL BEARING | 2 | |
| 5S7382 | 18 BOLT (3/8-16X1.375-IN) | 6 | |
| 4D8123 | 19 CLIP (LOOP) | 1 | |
| 5F3144 | 20 SEAL-O-RING | 1 | |
| 5K5959 | 21 SEAL-O-RING | 1 | |
| 5P5299 | 22 SEAL-LIP TYPE | 1 | |
| 7X0332 | 23 BOLT (1/2-13X4.5-IN) | 4 | |
| 7X0481 | 24 BOLT (1/2-13X8-IN) | 4 | |
| 7X7730 | 25 PLUG-PIPE | 1 | |
| 8N9764 | 26 HUB-FAN PULLEY | 1 | |
| 8N9765 | 27 SPACER (52X70X66-MM THK) | 1 | |
| 8N9766 | 28 SPACER | 1 | |
| 8N9768 | 29 WASHER-RETAINING (20.5X75X25-MM THK) | 1 | |
| 8T4223 | 30 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4896 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 5P2566 | 32 BOLT (1/2-13X1.5-IN) | 4 | |
| 8T4183 | 33 BOLT (M12X1.75X40-MM) | 4 |
