System And Components
466-2139 DRIVE GP-FANS/N AGC1-UP; 3PR1-UP
Group No: 466-2139
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3H0120 | 1 ELBOW | 1 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 6U1989 | 3 VALVE-RELIEF | 1 | |
| 8N6710 | 4 V-BELT SET (INCLUDES 4-BELTS) | 1 | |
| 8N9765 | 5 SPACER (52X70X66-MM THK) | 1 | |
| 8N9766 | 6 SPACER | 1 | |
| 8N9768 | 7 WASHER-RETAINING (20.5X75X25-MM THK) | 1 | |
| 2662415 | 8 PULLEY | 1 | |
| 4934496 | 9 ADAPTER | 1 | |
| 3158228 | 10 BRACKET AS | 1 | |
| 8H9189 | DOWEL | 1 | |
| 1114379 | SHAFT-TIGHTENER | 1 | |
| 3158252 | 11 PULLEY-FAN (4-GROOVE) | 1 | |
| 3272476 | 12 SPRING AS | 2 | |
| 3272533 | 13 HOSE AS | 1 | |
| 3343974 | 14 HUB-FAN PULLEY | 1 | |
| 3436348 | 15 BRACKET AS | 1 | |
| 3436391 | 16 ADAPTER AS | 1 | |
| 1W5075 | SHAFT-FAN | 1 | |
| 2D6642 | BALL | 1 | |
| 3803118 | 17 BRACKET | 2 | |
| 3803120 | 18 BELT TIGHTENER GP | 1 | |
| 3803127 | 19 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4481522 | 20 STUD-TAPERLOCK (1/2X13-THD) | 3 | |
| 1782255 | 21 PIN | 2 | |
| 1984778 | 22 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 7X3179 | 23 BOLT (3/4-10X9-IN) | 1 | |
| 1T0210 | 24 BALL BEARING | 2 | |
| 2284710 | 25 SPACER (13.8X30X20-MM THK) | 2 | |
| 3B4627 | 26 PIN-COTTER | 2 | |
| 3D0472 | 27 STUD-TAPERLOCK (1/2-13X2.80-IN) | 4 | |
| 5F3144 | 28 SEAL-O-RING | 1 | |
| 5K5959 | 29 SEAL-O-RING | 1 | |
| 5P1076 | 30 WASHER-HARD (13.5X30X4-MM THK) | 7 | |
| 5P5299 | 31 SEAL-LIP TYPE | 1 | |
| 5S7382 | 32 BOLT (3/8-16X1.375-IN) | 2 | |
| 5S7383 | 33 BOLT (3/8-16X1.75-IN) | 12 | |
| 2993330 | 34 NUT (1/2-13-THD) | 11 | |
| 7X0325 | 35 BOLT (1/2-13X2.5-IN) | 4 | |
| 7X0333 | 36 BOLT (1/2-13X4.75-IN) | 4 | |
| 7X0338 | 37 BOLT (1/2-13X6-IN) | 1 | |
| 7X3391 | 38 WASHER-HARD (13.5X32X6-MM THK) | 6 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 7 |
