System And Components
216-0822 HOUSING GP-FLYWHEELS/N LJW5430-UP
Group No: 216-0822
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3190785 | 1 SEAL GP-CRANKSHAFT (REAR)(FLYWHEEL HOUSING) | 1 | |
| 2160813 | 2 HOUSING AS-FLYWHEEL | 1 | |
| 1W3136 | BAFFLE | 1 | |
| 3F6795 | DOWEL | 2 | |
| 7N3011 | BUSHING | 1 | |
| 3318552 | 3 GASKET | 1 | |
| 2314470 | 4 BOLT (3/8-16X6.25-IN) | 1 | |
| 2314471 | 5 BOLT (1/2-13X6.5-IN)(MARKED X) | 8 | |
| 0S1619 | 6 BOLT (3/8-16X3-IN)(MARKED Y) | 11 | |
| 5B2638 | 7 BOLT (3/8-16X5.25-IN)(MARKED Z) | 16 | |
| 5M2894 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK)(MARKED V) | 34 | |
| 5P7814 | 9 SEAL-O-RING | 1 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK)(MARKED X) | 8 | |
| 2147568 | 11 SEAL-O-RING | 5 | |
| 8S9191 | 12 BOLT (3/8-16X4-IN)(MARKED V) | 6 | |
| 9S8003 | 13 PLUG (1/2-20-THD) | 1 | |
| 9S8004 | 14 PLUG (9/16-18-THD) | 5 |
