System And Components
231-0211 LINES GP-ENGINE OIL FILTERS/N LJW5430-UP
Group No: 231-0211
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1116 | 1 BODY-BYPASS | 1 | |
| 2P4305 | 2 GASKET | 2 | |
| 4N0861 | 3 COVER | 1 | |
| 4N0865 | 4 GASKET | 1 | |
| 4N2357 | 5 FILTER GP-ENGINE OIL | 1 | |
| 4N8411 | 6 TUBE-COOLER BYPASS | 1 | |
| 4N8600 | 7 ADAPTER-BASE | 1 | |
| 5G6504 | 8 LUG | 4 | |
| 6G2168 | 9 BLOCK | 1 | |
| 8C3445 | 10 CAP-DUST | 1 | |
| 9F6304 | 11 SPRING | 2 | |
| 9M0853 | 12 PLUNGER-VALVE | 2 | |
| 2483329 | 13 TUBE AS | 1 | |
| 2483330 | 14 TUBE AS | 1 | |
| 2715513 | 15 BRACKET | 1 | |
| 2814699 | 16 SUPPORT | 1 | |
| 2814700 | 17 SUPPORT AS | 1 | |
| 2814701 | 18 BRACKET | 1 | |
| 0617540 | 19 SEAL-O-RING | 5 | |
| 0L2070 | 20 BOLT (3/8-16X2.25-IN) | 5 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 8 | |
| 0S1591 | 22 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 10 | |
| 0S1608 | 24 BOLT (3/8-16X3.75-IN) | 1 | |
| 0T0065 | 25 BOLT (3/8-16X3.5-IN) | 3 | |
| 0T0772 | 26 BOLT (7/16-14X1.5-IN) | 12 | |
| 1A1460 | 27 BOLT (1/2-13X2-IN) | 4 | |
| 1A2029 | 28 BOLT (3/8-16X1.125-IN) | 4 | |
| 1L8793 | 29 BOLT-SOCKET HEAD (3/8-16X2-IN) | 4 | |
| 3B1915 | 30 BOLT (3/8-16X1.375-IN) | 7 | |
| 3P0650 | 31 SEAL-O-RING | 3 | |
| 4F5192 | 32 BOLT (7/16-14X3-IN) | 4 | |
| 4N8770 | 33 ELBOW-COOLER OUTLET | 1 | |
| 5M2894 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 19 | |
| 5P8068 | 35 SEAL-O-RING | 1 | |
| 5P8244 | 36 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 5P8245 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P9890 | 38 SEAL-O-RING | 2 | |
| 6V5048 | 39 SEAL-O-RING | 2 | |
| 6V5050 | 40 SEAL-O-RING | 1 | |
| 8C3446 | 41 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 9S4183 | 42 PLUG (1-1/16-12-THD) | 1 | |
| 9S8002 | 43 PLUG (7/16-20-THD) | 1 |
