System And Components
460-6748 PIPE GP-EXHAUSTS/N AGC1-UP; 3PR1-UP
Group No: 460-6748
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1984777 | 1 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 2312812 | 2 SEAL-RING | 1 | |
| 2509182 | 3 COVER | 1 | |
| 3546789 | 4 BELLOWS AS | 2 | |
| 3809976 | 5 TUBE AS | 1 | |
| 5098551 | 6 TUBE AS | 1 | |
| 5098552 | 7 TUBE AS | 1 | |
| 5098554 | 8 BRACKET AS | 1 | |
| 5104377 | 9 PIPE AS | 1 | |
| 5127898 | 10 PLATE AS | 1 | |
| 6C3241 | 11 BOLT (1/2-13X1.5-IN) | 2 | |
| 8T2502 | 12 BOLT (3/8-16X1.125-IN) | 8 | |
| 2659596 | 13 WASHER-HARD (13.5X30X9-MM THK) | 6 | |
| 2W9067 | 14 SLEEVE AS | 1 | |
| 3460335 | 15 CLAMP-BAND | 2 | |
| 5S7382 | 16 BOLT (3/8-16X1.375-IN) | 2 | |
| 4L9337 | 17 BOLT (3/8-16X1.5-IN) | 4 | |
| 5T6432 | 18 ELBOW | 1 | |
| 6V7687 | 19 LOCKNUT (M12X1.75-THD) | 2 | |
| 7W2033 | 20 CLIP (TAB) | 2 | |
| 7W2034 | 21 CLIP (SLOT) | 2 | |
| 8T4910 | 22 BOLT (M12X1.75X60-MM) | 2 | |
| 9N1941 | 23 CLAMP-V BAND | 2 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 12 |
