System And Components
470-5243 WIRING GP-COMMUNICATIONS/N AGC1-UP; 3PR1-UP
Group No: 470-5243
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 11 | |
| 2S9727 | 2 GROMMET | 1 | |
| 2504674 | 3 BOOT-RUBBER | 1 | |
| 2934950 | 4 FILM-IDENTIFICATION (DISCONNECT) | 1 | |
| 8T4983 | 5 CLAMP-HOSE | 1 | |
| 1114838 | 6 CLIP | 1 | |
| 3858201 | 7 CAP AS-CONNECTOR | 2 | |
| 4P7581 | 8 CLIP (LADDER) | 1 | |
| 8T4133 | 9 NUT (M10X1.5-THD) | 1 | |
| 8T4191 | 10 BOLT (M10X1.5X16-MM) | 3 | |
| 3523968 | 11 CLIP (LADDER) | 1 | |
| 3534515 | 12 SWITCH GP-TOGGLE (COMMUNICATION ON/OFF) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3538773 | 13 CABLE AS-COAXIAL | 1 | |
| 4H2558 | 14 GROMMET | 1 | |
| 5M3062 | 15 BOLT (3/8-16X0.75-IN) | 1 | |
| 6D3479 | 16 CLIP (LOOP) | 1 | |
| 6K8178 | 17 CLIP (LOOP) | 3 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4136 | 20 BOLT (M10X1.5X25-MM) | 1 |
