347-5854 AIR COMPRESSOR GPS/N 4YC1-UP; 4XJ1-UP

Group No: 347-5854

Part Number	Part Name	Qty
7W9834	1 VALVE-REGULATOR (AIR COMPRESSOR)	1
8M7065	2 GASKET (AIR INLET)	1
8T9023	3 CONNECTOR-O-RING	1
1122406	4 GOVERNOR GP-AIR COMPRESSOR	1
1352145	5 BRACKET	1
1598091	6 BRACKET	1
2614881	7 AIR COMPRESSOR GP	1
0S0509	8 BOLT (3/8-16X0.75-IN)	1
0S1585	9 BOLT (1/2-13X1.5-IN)	1
0S1595	10 BOLT (1/2-13X1.25-IN)	2
1242111	11 COUPLING-PERMANENT	1
1242119	12 COUPLING-PERMANENT	2
1242151	13 COUPLING-PERMANENT	2
1242158	14 COUPLING-PERMANENT	1
1463342	15 COUPLING-PERMANENT	1
1463359	16 COUPLING-PERMANENT	2
1463366	17 COUPLING-PERMANENT	1
1641404	18 SPACER (10.67X16.95X23-MM THK)	1
1808424	19 SEAL-O-RING	4
1B2790	20 BOLT (5/16-18X1.375-IN)	2
1F7958	21 NUT-FULL (1/2-13-THD)	1
2T1922	22 ELBOW	2
2Y5829	23 NUT (M10X1.5-THD)	1
3D2824	24 SEAL-O-RING	1
4J5477	25 SEAL-O-RING	2
5K8451	26 CLIP (LOOP)	1
5M2894	27 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
5P7468	28 CLIP (SLOT)	1
5P7469	29 CLIP (TAB)	1
5P8245	30 WASHER-HARD (13.5X25.5X3-MM THK)	4
6V1820	31 BOLT (M10X1.5X30-MM)	1
6V3250	32 SEAL-O-RING	1
6V3251	33 SEAL-O-RING	1
6V4249	34 BOLT (M10X1.5X50-MM)	1
6V5063	35 SEAL-O-RING	1
6V5839	36 WASHER (11X21X2.5-MM THK)	3
6V6609	37 SEAL-O-RING	1
6V8627	38 ELBOW	1
6V8639	39 CONNECTOR	1
6V8642	40 CONNECTOR	1
6V8675	41 BOLT (M12X1.75X35-MM)	3
6V9746	42 SEAL-O-RING	2
7J9108	43 SEAL-O-RING	2
7X0492	44 ELBOW	1
8C6873	45 CONNECTOR	1
8C6874	46 CONNECTOR	1
8J8197	47 CLIP	1
8T5429	48 ELBOW	1
8T9518	49 GROMMET (24-MM ID)	1
9M1974	50 WASHER-HARD (8.8X16X2-MM THK)	2
9M8406	51 CLIP (LOOP)	1
9X8250	52 CLIP (LOOP)	1
1226867	53 HOSE (10.3-IN)
2247700	54 HOSE (61-CM)
2247700	54A HOSE (225-CM)
1247115	55 HOSE-HYDRAULIC (27-IN)
1226871	56 HOSE-HYDRAULIC (60.3-IN)
1446142	57 SEAL-INTEGRAL	1
