System And Components
347-5838 PIPE GP-EXHAUSTS/N 4YC1-UP; 4XJ1-UP
Group No: 347-5838
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W9067 | 1 SLEEVE AS | 1 | |
| 9N1941 | 2 CLAMP-V BAND | 4 | |
| 2361161 | 3 ELBOW | 1 | |
| 2361637 | 4 SEAL | 2 | |
| 2509182 | 5 COVER | 1 | |
| 3028136 | 6 CLAMP-BAND | 2 | |
| 3051257 | 7 GASKET | 1 | |
| 3060297 | 8 BELLOWS AS | 1 | |
| 3475863 | 9 BRACKET | 1 | |
| 3475864 | 10 BRACKET | 1 | |
| 3475866 | 11 TUBE AS | 1 | |
| 3475867 | 12 BRACKET | 1 | |
| 3475872 | 13 TUBE AS | 1 | |
| 3544018 | 14 TUBE AS | 1 | |
| 3544019 | 15 TUBE AS | 1 | |
| 0S1585 | 16 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1594 | 17 BOLT (3/8-16X1-IN) | 4 | |
| 1F7958 | 18 NUT-FULL (1/2-13-THD) | 2 | |
| 3E4353 | 19 WASHER-HARD (11X25X3-MM THK) | 4 | |
| 3J5389 | 20 PLUG (EXTERNAL) | 2 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P1075 | 22 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 5P8245 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5S7382 | 24 BOLT (3/8-16X1.375-IN) | 12 | |
| 6V1820 | 25 BOLT (M10X1.5X30-MM) | 6 | |
| 6V3822 | 26 BOLT (M10X1.5X35-MM) | 2 | |
| 6V5839 | 27 WASHER (11X21X2.5-MM THK) | 8 | |
| 7W2033 | 28 CLIP (TAB) | 2 | |
| 7W2034 | 29 CLIP (SLOT) | 2 | |
| 8T2502 | 30 BOLT (3/8-16X1.125-IN) | 6 | |
| 8T4896 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 |
