Assembly
100%

10R-3055 CYLINDER HEAD ASPART OF 20R-1182 KIT-ENGINE OVERHAUL

Group No: 10R-3055
Part NumberPart NameQty
8T67572 PLUG-PIPE3
17536173 INSERT-VALVE SEAT (INLET)(STANDARD)12
1670643INSERT-VALVE SEAT (0.76-MM OS, INLET)
1704738INSERT-VALVE SEAT (0.51-MM OS, INLET)
15275824 INSERT-VALVE SEAT (EXHAUST)(STANDARD)12
1670642INSERT-VALVE SEAT (0.76-MM OS, EXHAUST)
1704737INSERT-VALVE SEAT (0.51-MM OS, EXHAUST)
21655825 BUSHING (STANDARD)7
2170751BUSHING (0.25-MM OS)
2170752BUSHING (0.762-MM OS)
2613429BUSHING (1.778-MM OS)
2613430BUSHING (1.27-MM OS)
26349206 SLEEVE-INJECTOR (INLET)6
3B06457 PLUG-CUP20
3B06238 PLUG-CUP17
12273759 GUIDE-VALVE (STANDARD)24
1220447GUIDE-VALVE (0.51-MM OS)
1228612GUIDE-VALVE (0.13-MM OS)
166290410 SEAL-O-RING12
9X743011 SEAL-O-RING6
