System And Components
230-2623 HOUSING & REGULATOR GPS/N BET1-UP
Group No: 230-2623
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9M1974 | 1 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1W4086 | 2 COVER AS-REGULATOR | 1 | |
| 2H1193 | 2A FERRULE | 1 | |
| 3S9643 | 2B SEAL-LIP TYPE | 1 | |
| 5M6213 | 2C PLUG-PIPE (1/4-18-THD) | 1 | |
| 4N0641 | 3 GASKET | 2 | |
| 4N1156 | 4 GASKET-REGULATOR COVER | 1 | |
| 4N1199 | 5 CLIP | 1 | |
| 4N3841 | 6 GASKET | 1 | |
| 4N6257 | 7 ADAPTER | 2 | |
| 4W4794 | 8 REGULATOR-WATER TEMPERATURE (92-DEG C) | 1 | |
| 7N1572 | 9 COVER-WATER PUMP | 1 | |
| 7W3587 | 11 ELBOW-BYPASS | 1 | |
| 1022240 | 12 SENSOR GP-TEMPERATURE (3-PIN)(COOLANT) | 1 | |
| 1123231 | 13 ADAPTER (1/2-14-THD) | 1 | |
| 1250434 | 14 SEAL-INTEGRAL | 1 | |
| 1255816 | 15 BONNET-OIL COOLER | 1 | |
| 1346054 | 16 SWITCH GP-FLOW (COOLANT) | 1 | |
| 2413916 | 17 BONNET AS | 1 | |
| 1567896 | 18 ELBOW | 1 | |
| 1567900 | 19 TUBE | 1 | |
| 1662795 | 20 BRACKET | 1 | |
| 0L1351 | 21 BOLT (3/8-16X0.875-IN) | 3 | |
| 0L2070 | 22 BOLT (3/8-16X2.25-IN) | 2 | |
| 0S1571 | 23 BOLT (3/8-16X1.75-IN) | 2 | |
| 0S1591 | 25 BOLT (3/8-16X1.5-IN) | 4 | |
| 0S1594 | 26 BOLT (3/8-16X1-IN) | 2 | |
| 0S1619 | 27 BOLT (3/8-16X3-IN) | 3 | |
| 1090076 | 28 SEAL-O-RING | 1 | |
| 1090077 | 29 SEAL-O-RING | 3 | |
| 1107753 | 30 SEAL-O-RING | 2 | |
| 1125282 | 31 SEAL-O-RING | 1 | |
| 1A2029 | 32 BOLT (3/8-16X1.125-IN) | 8 | |
| 2B2695 | 34 BOLT (5/16-18X0.875-IN) | 2 | |
| 2P2772 | 36 COVER | 1 | |
| 4N0933 | 37 GASKET | 1 | |
| 5M2894 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 7C0307 | 41 GASKET | 1 | |
| 7X7731 | 42 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8T6761 | 45 PLUG-PIPE (1-11-1/2 NPT THD) | 1 |
