System And Components
8N-9267 CYLINDER BLOCK GPS/N 11N1-UP
Group No: 8N-9267
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2906567 | 1 TUBE AS-OIL JET | 6 | |
| 8T6757 | 2 PLUG-PIPE | 3 | |
| 2021258 | 3 CYLINDER BLOCK GP | 1 | |
| 8T6763 | 4 PLUG-PIPE (1/4-18-THD) | 3 | |
| 1S9540 | 5 DOWEL | 2 | |
| 3S5496 | 6 SEAL-O-RING | 2 | |
| 7W6492 | 7 PLUG-PIPE (1/2-14-THD) | 1 | |
| 1195155 | 8 SEAL-O-RING | 1 | |
| 0307571 | 9 BOLT (3/8-16X1-IN) | 4 | |
| 4W8585 | 10 COVER | 1 | |
| 7W6081 | 11 GASKET | 1 | |
| 4N0683 | 12 DOWEL | 4 | |
| 4N1650 | 13 DOWEL | 2 | |
| 6I2981 | 14 PLATE-BLOCK | 1 | |
| 6I4024 | 15 GASKET-PLATE | 1 | |
| 8S9094 | 16 PLUG-ORIFICE | 1 | |
| 9S4190 | 17 PLUG-O-RING (7/8-14-THD)(STRAIGHT THREAD O-RING) | 1 | |
| 1144427 | 18 SEAL-O-RING | 1 | |
| 7X7732 | 19 PLUG-PIPE | 6 | |
| 1515925 | 20 BOLT (7/16-14-THD) | 6 | |
| 8T6764 | 21 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S8009 | 22 PLUG-O-RING (STRAIGHT THREAD O-RING) | 1 | |
| 1007399 | 23 PLUG | 2 | |
| 2500466 | 24 SEAL-O-RING | 2 | |
| 9S4182 | 25 PLUG (7/16-20-THD)(STRAIGHT THREAD O-RING) | 1 | |
| 9X7378 | 26 SEAL-O-RING | 1 | |
| 7W6534 | 27 PLUG-PIPE | 1 |
