System And Components
4N-6954 AIR COMPRESSOR GPPART OF 7N-6294 AIR COMPRESSOR GP
Group No: 4N-6954
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N2103 | 1 CRANKSHAFT AS | 1 | |
| 9F2247 | PLUG-PIPE | 1 | |
| 6N2102 | 2 ADAPTER AS | 1 | |
| 9F2247 | 3 PLUG-PIPE | 1 | |
| 7N0243 | 4 LOCK-ROD BOLT | 2 | |
| 6N2097 | 5 HEAD AS-COMPRESSOR (AIR) | 1 | |
| 3J5390 | PLUG (3/8-18-THD) | 1 | |
| 3J5389 | 6 PLUG (EXTERNAL) | 2 | |
| 6N2098 | 7 GASKET-CYLINDER HEAD | 1 | |
| 2B2695 | 8 BOLT (5/16-18X0.875-IN) | 2 | |
| 3B4505 | LOCKWASHER | 2 | |
| 8M7065 | 9 GASKET (AIR INLET) | 1 | |
| 5M6509 | 10 SEAL-O-RING | 2 | |
| 7N4837 | 11 PISTON AS-COMPRESSOR | 2 | |
| 5M6214 | 12 PLUG (1/8-27 PTF) | 2 | |
| 6N2100 | 13 COVER AS-REAR | 2 | |
| 6N2106 | 14 ROD AS-CONNECTING | 2 | |
| 6N0634 | 15 GASKET-COVER | 1 | |
| 6N2101 | 16 COVER-CRANKCASE | 1 | |
| 0L1351 | 17 BOLT (3/8-16X0.875-IN) | 6 | |
| 3B4506 | LOCKWASHER | 6 | |
| 9M0397 | 18 ADAPTER | 1 | |
| 0S1619 | 19 BOLT (3/8-16X3-IN) | 6 | |
| 5P0060 | 20 BOLT (7/16-14X0.75-IN) | 8 | |
| 3B4507 | 21 LOCKWASHER | 4 | |
| 8N3665 | 22 KIT-SEAL | 1 | |
| 6N2099 | 23 CRANKCASE AS-AIR COMPRESSOR | 1 | |
| 7N6172 | 24 BUSHING-COMPRESSOR | 2 | |
| 9M0381 | 25 INSERT-INLET VALVE | 2 | |
| 8N3666 | KIT-AIR COMPRESSOR | 1 | |
| 6N2109 | KIT-PISTON RING | 1 |
