System And Components
321-2698 AIR CLEANER GPS/N LCT1-109
Group No: 321-2698
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2544293 | 1 CAP GP-AIR CLEANER | 1 | |
| 5P0600 | CLAMP-HOSE | 1 | |
| 3817131 | 2 AIR CLEANER GP | 1 | |
| 3200711 | 3 HOSE | 1 | |
| 3497244 | 4 BRACKET | 1 | |
| 3497245 | 5 BRACKET | 1 | |
| 3497249 | 6 BRACKET | 1 | |
| 3497250 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4206456 | 8 COVER AS | 1 | |
| 5P4116 | WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 6V9189 | LOCKNUT (M8X1.25-THD) | 3 | |
| 8T7547 | BOLT (M8X1.25X30-MM) | 3 | |
| 3497271 | COVER AS | 1 | |
| 4206462 | PIPE-EXTENSION | 1 | |
| 2303671 | 9 CLAMP-T BOLT | 1 | |
| 2338350 | 10 CLAMP (T-BOLT) | 1 | |
| 7X7729 | 11 WASHER (11X25X3-MM THK) | 16 | |
| 8T4133 | 12 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 13 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4189 | 14 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4195 | 15 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T6466 | 17 BOLT (M10X1.5X60-MM) | 2 | |
| 5P4116 | 18 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 8T4908 | 19 BOLT (M8X1.25X25-MM) | 5 |
