System And Components
321-2698 AIR CLEANER GPS/N LCT1-UP
Group No: 321-2698
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N5991 | 1 HOSE | 1 | |
| 2544293 | 2 CAP GP-AIR CLEANER | 1 | |
| 5P0600 | CLAMP-HOSE | 1 | |
| 3200711 | 3 HOSE | 1 | |
| 3497244 | 4 BRACKET | 1 | |
| 3497245 | 5 BRACKET | 1 | |
| 3497249 | 6 BRACKET | 1 | |
| 4506723 | 7 AIR CLEANER GP | 1 | |
| 3979529 | 8 COVER AS | 1 | |
| 4204984 | 9 TUBE | 1 | |
| 4322635 | 10 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 4322636 | 11 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 2W6466 | 12 CLAMP | 2 | |
| 6V7744 | 13 LOCKNUT (M10X1.5-THD) | 2 | |
| 7X0579 | 14 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 12 | |
| 8T4136 | 16 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4185 | 17 BOLT (M10X1.5X50-MM) | 2 | |
| 8T4189 | 18 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4195 | 19 BOLT (M10X1.5X30-MM) | 11 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 21 BOLT (M8X1.25X25-MM) | 5 | |
| 8T4986 | 22 CLAMP-HOSE | 1 | |
| 8T4988 | 23 CLAMP-HOSE | 1 | |
| 8T4990 | 24 CLAMP-HOSE | 2 | |
| 8T7934 | 25 WASHER-HARD (11X21X5-MM THK) | 7 |
