System And Components
440-2168 AIR CLEANER GPS/N WTC1-480
Group No: 440-2168
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4402167 | 1 ADAPTER | 1 | |
| 5S3919 | 2 HOSE | 1 | |
| 3321114 | 3 PLENUM | 1 | |
| 3496259 | 4 AIR CLEANER GP | 1 | |
| 3505808 | 5 PRECLEANER GP | 1 | |
| 3665747 | 6 CLAMP AS | 1 | |
| 4745584 | 7 PIPE AS | 1 | |
| 4402159 | 8 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 4402161 | 9 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4526168 | 10 BRACKET AS | 1 | |
| 6G2263 | SPACER (10.5X19X28.5-MM THK) | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 4402164 | 11 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 4402166 | 12 TUBE | 1 | |
| 4402169 | 13 TUBE | 1 | |
| 4526159 | 14 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5027089 | 15 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 4526161 | 16 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 5 | |
| 3887007 | 17 CLAMP-BENT BOLT | 1 | |
| 1984776 | 18 WASHER-HARD (8.8X20X8-MM THK) | 8 | |
| 1984777 | 19 WASHER-HARD (11X25X10-MM THK) | 28 | |
| 2087448 | 20 CLAMP | 1 | |
| 2240807 | 21 CLAMP | 1 | |
| 7W2033 | 22 CLIP (TAB) | 2 | |
| 7W2034 | 23 CLIP (SLOT) | 2 | |
| 7X7729 | 24 WASHER (11X25X3-MM THK) | 2 | |
| 8T4186 | 25 BOLT (M10X1.5X40-MM) | 8 | |
| 8T4195 | 26 BOLT (M10X1.5X30-MM) | 16 | |
| 8T4196 | 27 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4908 | 28 BOLT (M8X1.25X25-MM) | 6 | |
| 8T6466 | 29 BOLT (M10X1.5X60-MM) | 4 | |
| 8T7547 | 30 BOLT (M8X1.25X30-MM) | 2 | |
| 9X6654 | 31 CLAMP-HOSE | 2 |
