System And Components
466-6612 LINES GP-AIRS/N WTC1-UP
Group No: 466-6612
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E4096 | 1 CAP | 10 | |
| 1069858 | 2 HOSE | 1 | |
| 1770581 | 3 HOSE | 1 | |
| 2546034 | 4 HOSE-ELBOW | 2 | |
| 3217967 | 5 HOSE | 1 | |
| 3867455 | 6 TUBE | 1 | |
| 3896063 | 7 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4204461 | 8 TUBE | 1 | |
| 4214815 | 9 TUBE AS | 1 | |
| 4666613 | 10 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1984777 | 11 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 2094578 | 12 CLAMP-T BOLT | 10 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4186 | 15 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 17 BOLT (M10X1.5X35-MM) | 2 | |
| 9X2646 | 18 CLIP (SLOT) | 3 | |
| 9X2647 | 19 CLIP (TAB) | 3 |
