System And Components
440-2151 LINES GP-ENGINE OILS/N WTL1-UP
Group No: 440-2151
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C3445 | 1 CAP-DUST | 1 | |
| 1645602 | 2 PLUG AS | 1 | |
| 8J5914 | PLUG | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 1837264 | 3 VALVE AS-FLUID SAMPLING (ENGINE OIL) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3295466 | 4 ELBOW AS | 1 | |
| 6V9009 | ELBOW | 1 | |
| 2287094 | SEAL-O-RING | 1 | |
| 2287096 | SEAL-O-RING | 1 | |
| 4402152 | 5 HOSE AS | 1 | |
| 4402153 | 6 TUBE AS | 1 | |
| 4402154 | 7 HOSE AS | 1 | |
| 4402156 | 8 TUBE AS | 1 | |
| 4402157 | 9 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1488334 | 10 CONNECTOR AS | 1 | |
| 8T3611 | CONNECTOR | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 1488373 | 11 ELBOW AS | 1 | |
| 8C3364 | ELBOW | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V1876 | 12 GROMMET | 1 | |
| 6V8400 | 13 SEAL-O-RING | 2 | |
| 7C4355 | 14 CLIP | 2 | |
| 7G5984 | 15 CLIP (TAB) | 1 | |
| 7G5985 | 16 CLIP (SLOT) | 1 | |
| 7X7729 | 17 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4195 | 20 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4196 | 21 BOLT (M10X1.5X35-MM) | 3 | |
| 7D7233 | 22 CLIP (LOOP) | 1 |
