System And Components
100-3025 COOLER GP-FLTR BASE & ENG OILS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 100-3025
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P8870 | 1 PIPE-PUMP OUTLET | 1 | |
| 1A2029 | 2 BOLT (3/8-16X1.125-IN) | 8 | |
| 8S5409 | 3 GASKET | 2 | |
| 3602740 | 4 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 1003024 | 5 BONNET | 1 | |
| 8T6761 | 6 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 2P7734 | 7 ELBOW-OUTLET | 1 | |
| 5P8118 | 8 SEAL-O-RING | 2 | |
| 8T6767 | 9 PLUG-PIPE (3/8-18-THD) | 1 | |
| 1D4540 | 10 BOLT (5/16-18X2.75-IN) | 1 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1H5514 | 12 BOLT (5/16-18X1.625-IN) | 3 | |
| 2P7732 | 13 ELBOW | 1 | |
| 3P1155 | 14 SEAL-O-RING | 2 | |
| 1T0765 | 15 BOLT (3/8-16X1-IN) | 2 | |
| 5M2894 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 0S1591 | 17 BOLT (3/8-16X1.5-IN) | 2 | |
| 7X7731 | 18 PLUG-PIPE (3/4-14-THD) | 1 | |
| 8N4457 | 19 BASE GP-OIL FILTER | 1 |
