System And Components
2W-2271 COOLER GP-FLTR BASE & ENG OILS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 2W-2271
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W5240 | 1 PIPE-PUMP OUTLET | 1 | |
| 7N0165 | 2 CORE AS-OIL COOLER (ENGINE) | 1 | |
| 1005985 | 3 BONNET-OIL COOLER | 1 | |
| 8N4457 | 4 BASE GP-OIL FILTER | 1 | |
| 1A2029 | 5 BOLT (3/8-16X1.125-IN) | 3 | |
| 1T0765 | 6 BOLT (3/8-16X1-IN) | 1 | |
| 0L2070 | 7 BOLT (3/8-16X2.25-IN) | 1 | |
| 5S6051 | 8 GASKET | 2 | |
| 9M1974 | 9 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1D4540 | 10 BOLT (5/16-18X2.75-IN) | 1 | |
| 1B9575 | 11 BOLT (5/16-18X1.56-IN) | 3 | |
| 5P8118 | 12 SEAL-O-RING | 2 | |
| 8T6761 | 13 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 7X7731 | 14 PLUG-PIPE (3/4-14-THD) | 1 | |
| 8T6767 | 15 PLUG-PIPE (3/8-18-THD) | 1 | |
| 0S1588 | 16 BOLT (3/8-16X1.25-IN) | 3 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 2A3541 | 18 GASKET | 1 | |
| 6B0041 | 19 COVER | 1 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 0L1351 | 21 BOLT (3/8-16X0.875-IN) | 2 |
