System And Components
2W-2410 GOVERNOR GPS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 2W-2410
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W6523 | 1 PLUG | 1 | |
| 8N3259 | 2 COVER-HIGH IDLE | 1 | |
| 7N2594 | 3 SETSCREW-SLOTTED | 2 | |
| 5P6945 | 4 BOLT (1/4-20X1.125-IN) | 2 | |
| 3J7354 | 5 SEAL-O-RING | 1 | |
| 9A7377 | 6 VALVE AS-NEEDLE (THROTTLE RESPONSE) | 1 | |
| 4N5485 | 6A BODY-VALVE | 1 | |
| 6H9691 | 6B SEAL-O-RING | 1 | |
| 4N5484 | 6C VALVE-NEEDLE | 1 | |
| 5F9144 | 6D SEAL-O-RING | 1 | |
| 0S1616 | 8 BOLT (1/4-20X1-IN) | 6 | |
| 7N8780 | 9 COVER AS-CONTROL | 1 | |
| 1389507 | 9A SEAL-LIP TYPE | 1 | |
| 0310216 | 10 BOLT (1/4-20X0.75-IN) | 3 | |
| 1503728 | 11 GASKET | 1 | |
| 3P0009 | 12 INSULATOR | 1 | |
| 1P2497 | 13 BOLT-HEAD (10-24X1-IN) | 2 | |
| 8N3258 | 14 COVER-LOAD STOP | 1 | |
| 6D3897 | 15 BOLT (8-32X0.5-IN) | 1 | |
| 6L5897 | 16 BOLT (1/4-20X0.875-IN) | 2 | |
| 2W6104 | 17 BLOCK AS-STOP | 1 | |
| 2W6103 | DOWEL | 1 | |
| 1W4243 | 18 SPRING-BUMPER | 1 | |
| 8N2488 | 19 BOLT-LOAD STOP | 1 | |
| 8N3256 | 20 COLLAR-LOAD STOP | 1 | |
| 8L5832 | 21 NUT-HEX (10-32-THD) | 1 | |
| 9Y4701 | 22 SETSCREW-SOCKET (10-32X1.38-IN) | 1 | |
| 2P9556 | 23 WASHER (1.17X1.5X0.06-IN THK) | 1 | |
| 1N3800 | 24 SLEEVE-RACK CONTROL | 1 | |
| 6N3504 | 25 SEAT-GOVERNOR SPRING | 1 | |
| 2W2216 | 26 SPRING-LINK | 1 | |
| 2M7819 | 27 RING-RETAINING | 2 | |
| 1N3802 | 28 SEAT-SPRING | 1 | |
| 8N2507 | 29 PISTON AS-SERVO | 1 | |
| 7C0791 | CYLINDER AS | 1 | |
| 1W4098 | PISTON-GOVERNOR SERVO | 1 | |
| 8N2505 | 29A VALVE-GOVERNOR SERVO | 1 | |
| 7W0250 | 29B SLEEVE | 1 | |
| 5P9757 | 29C SEAL-O-RING | 1 | |
| 8N3168 | 30 LEVER-THROTTLE | 1 | |
| 2W6102 | 31 LEVER-SPRING SEAT | 1 | |
| 2W7400 | 32 SPRING | 1 | |
| 8N3087 | 33 STOP-IDLE DETENT | 1 | |
| 4N2953 | 34 RING-LOCK | 1 | |
| 7E4892 | 35 RACE-THRUST BEARING | 2 | |
| 7M7219 | 36 BEARING-THRUST | 1 | |
| 4W6868 | 37 RISER-GOVERNOR | 1 | |
| 2N0828 | 38 WASHER | 2 | |
| 8N2495 | 39 HOUSING AS-GOVERNOR | 1 | |
| 8S6814 | PIN (7.78MM OD X 12.7MM LONG) | 4 | |
| 4F6024 | PIN (6.193MM OD X 8.0MM LONG) | 2 | |
| 8N2503 | 40 ACTUATOR AS-GOVERNOR | 1 | |
| 7N7268 | SEAT-SPRING | 1 | |
| 4N6410 | 40A SPRING-DASHPOT | 1 | |
| 4N6408 | 41 PISTON AS | 1 | |
| 4N6404 | 41A RING-RETAINING | 1 | |
| 4N6406 | 41B RING-SPACER | 1 | |
| 4N6407 | 41C SPOOL-DASHPOT | 1 | |
| 7N8785 | 42 SHAFT-PIVOT | 1 | |
| 1503730 | 43 GASKET | 1 | |
| 7N7270 | 44 SLEEVE-SPRING | 2 | |
| 7N8821 | 45 RING-RETAINING | 3 | |
| 3K5733 | 46 SPRING | 1 | |
| 8N2501 | 47 HOUSING AS-GOVERNOR | 1 | |
| 8N3945 | BUSHING-TERMINAL | 1 | |
| 7E5346 | VALVE AS (FUEL CHECK) | 1 | |
| 8N2499 | 47A SPRING-GUIDE | 1 | |
| 3D8317 | 47B RING-RETAINING | 1 | |
| 4N0260 | 47C SEAL-LIP TYPE | 1 | |
| 2F2290 | 47D PLUG-CORE | 1 | |
| 2W9305 | 52 PLATE-THROTTLE | 2 | |
| 4N0432 | 53 BALL BEARING | 1 | |
| 7N2171 | 55 RING-RETAINING | 4 | |
| 7N2172 | 56 PIN | 2 | |
| 6I2003 | 57 GASKET | 1 | |
| 7N8775 | 58 NUT-HIGH IDLE | 1 | |
| 5P0537 | 59 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T0328 | 60 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 6I2004 | 61 GASKET | 1 | |
| 7W4272 | 62 NUT-SEALING (5/16-18-THD) | 1 |
