System And Components
1W-1695 PUMP GP-FUEL TRANSFERS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 1W-1695
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1698 | 1 HOUSING-TRANSFER PUMP | 1 | |
| 1W1699 | 2 COVER | 1 | |
| 1W5912 | 3 GUIDE & TAPPET AS | 1 | |
| 7N8821 | 3A RING-RETAINING | 1 | |
| 6J2419 | 4 SEAL-O-RING | 1 | |
| 7E2464 | 5 VALVE AS-CHECK (FUEL TRANSFER PUMP) | 3 | |
| 3D2824 | 6 SEAL-O-RING | 1 | |
| 6F6672 | 7 SEAL-O-RING | 1 | |
| 3D2898 | 8 SEAL-O-RING | 1 | |
| 5P8215 | 9 SEAL-O-RING | 1 | |
| 7W0134 | 10 SPRING-PUMP | 1 | |
| 8N2637 | 11 WASHER (21.3X29.5X1.6-MM THK) | 1 | |
| 7E3667 | 12 SPACER (25.46X28.86X1.84-MM THK) | 1 | |
| 8N2641 | 13 SLEEVE | 1 | |
| 1W1669 | 14 PISTON | 1 | |
| 0S1615 | 15 BOLT (1/4-20X0.75-IN) | 2 | |
| 6D8498 | 16 SCREW-HEAD | 2 | |
| 8N2640 | 17 COVER | 1 | |
| 7E4656 | 18 RETAINER | 1 |
