System And Components
111-3768 PUMP GP-GOV & FUEL INJS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 111-3768
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D6392 | 1 SEAL-O-RING | 1 | |
| 0335879 | 2 SEAL-O-RING | 1 | |
| 8J8343 | 3 SEAL-O-RING | 1 | |
| 5H6552 | 4 SETSCREW-SOCKET (10-32X1.25-IN) | 1 | |
| 1115162 | 5 CONTROL GP-FUEL RATIO | 1 | |
| 4W5735 | 6 LEVER AS-PIVOT | 1 | |
| 6V6835 | 7 SETSCREW-SOCKET (10-32X0.625-IN) | 1 | |
| 8L5832 | 8 NUT-HEX (10-32-THD) | 1 | |
| 4W5734 | 9 LEVER AS | 1 | |
| 2W2410 | 10 GOVERNOR GP | 1 | |
| 1503726 | 11 GASKET | 1 | |
| 3J1907 | 12 SEAL-O-RING | 1 | |
| 1113769 | 13 PUMP GP-FUEL INJECTION | 1 | |
| 6V5894 | 14 BOLT (1/4-20X3.75-IN) | 2 | |
| 7C8993 | 15 FASTENER GP-FUEL INJ PUMP | 1 | |
| 7N2176 | 16 PIN-DETENT | 1 | |
| 7N1052 | 17 DOWEL | 1 | |
| 8N3094 | 18 SPRING-DETENT | 1 | |
| 1W8668 | 19 TORQUE CONTROL GP | 1 | |
| 8N5784 | 20 DEFLECTOR-PULSE | 1 | |
| 8L9790 | 21 SPRING | 1 | |
| 8N3088 | 22 SHAFT AS-THROTTLE | 1 | |
| 2W5448 | 23 COVER | 1 | |
| 1440477 | GASKET | 1 | |
| 7N9907 | 24 COVER | 1 | |
| 1503727 | GASKET-FUEL | 1 | |
| 8M8515 | 25 SEAL-O-RING | 1 | |
| 5P6620 | 26 SEAL-O-RING | 1 | |
| 8L5832 | 27 NUT-HEX (10-32-THD) | 1 | |
| 5P0537 | 28 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8N6680 | 29 SCREEN AS (ORIFICE) | 1 |
