System And Components
2P-8160 GEAR GP-REARS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 2P-8160
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P3201 | 1 BOLT-WASHER HEAD (3/8-16X1-IN) | 6 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 9M0672 | 3 COVER-PTO HOUSING | 1 | |
| 9M0673 | 4 GASKET | 1 | |
| 9S7034 | 5 COVER AS | 1 | |
| 5M6214 | 6 PLUG (1/8-27 PTF) | 2 | |
| 9S6729 | 7 BUSHING | 2 | |
| 7L4265 | 8 WASHER-THRUST | 2 | |
| 3F6795 | 9 DOWEL | 4 | |
| 3H4970 | 10 SEAL-O-RING | 1 | |
| 9S6762 | 11 GASKET | 1 | |
| 2P4701 | 12 SHAFT AS-GEAR | 1 | |
| 9S6741 | 13 WASHER-THRUST | 1 | |
| 3F6795 | 14 DOWEL | 2 | |
| 9S6741 | 15 WASHER-THRUST | 1 | |
| 7N5825 | 16 GEAR (106 TEETH) | 1 | |
| 7N5819 | 17 GEAR-HYDRAULIC PUMP DRIVE (73 TEETH) | 1 | |
| 7N5810 | 18 GEAR AS-IDLER (117 TEETH) | 1 | |
| 2P4698 | 19 BUSHING | 1 | |
| 0V0375 | 20 BOLT (1/2-13X3.25-IN) | 3 | |
| 4F1450 | 21 STUD | 3 | |
| 3P3202 | 22 SPRING | 13 | |
| 5F3106 | 23 SEAL-O-RING | 1 | |
| 4D3704 | 24 WASHER-HARD (17X30X5-MM THK) | 2 | |
| 0S1566 | 25 BOLT (5/8-11X1.5-IN) | 2 | |
| 7N8374 | 26 COVER-PUMP | 1 | |
| 1B4203 | 27 NUT-FULL (3/8-24-THD) | 3 | |
| 7N5815 | 28 GEAR-CRANKSHAFT REAR (76 TEETH) | 1 |
