System And Components
2P-6122 HOUSING GP-FLYWHEELS/N 6NC1-UP; R6J1-UP; 08Z1-UP
Group No: 2P-6122
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P4691 | 1 HOUSING AS-FLYWHEEL | 1 | |
| 3F6795 | 2 DOWEL | 6 | |
| 9S6729 | 3 BUSHING | 2 | |
| 3D0490 | 4 STUD-TAPERLOCK (1/2-13X1.97-IN) | 12 | |
| 7L4265 | 5 WASHER-THRUST | 2 | |
| 3F0957 | 6 DOWEL | 4 | |
| 5M6214 | 7 PLUG (1/8-27 PTF) | 2 | |
| 2A3798 | 8 DOWEL | 2 | |
| 0S1585 | 9 BOLT (1/2-13X1.5-IN) | 2 | |
| 0S1587 | 10 BOLT (1/2-13X1.75-IN) | 9 | |
| 2P3201 | 11 BOLT-WASHER HEAD (3/8-16X1-IN) | 4 | |
| 8M3107 | 12 COVER | 1 | |
| 2S4750 | GASKET | 1 | |
| 5M6213 | 13 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9H5921 | 14 GASKET | 1 | |
| 0S1585 | 15 BOLT (1/2-13X1.5-IN) | 1 | |
| 0S1587 | 16 BOLT (1/2-13X1.75-IN) | 1 | |
| 0323180 | 17 BOLT (1/2-13X1.625-IN) | 2 |
