System And Components
2W-0106 LINES GP-TURBOCHARGER OILS/N 08Z1-86071
Group No: 2W-0106
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B1915 | 1 BOLT (3/8-16X1.375-IN) | 2 | |
| 1S6595 | 2 GASKET-OIL SUPPLY | 1 | |
| 4W6081 | 3 TUBE AS-SUPPLY | 1 | |
| 1S4810 | 4 GASKET-OIL DRAIN | 1 | |
| 1A2029 | 5 BOLT (3/8-16X1.125-IN) | 5 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6N6033 | 7 CLIP | 2 | |
| 1D4716 | 8 NUT-FULL (5/16-18-THD) | 1 | |
| 8M0505 | 9 ADAPTER | 1 | |
| 3K0360 | 10 SEAL-O-RING | 2 | |
| 8M5253 | 11 SEAL-O-RING | 1 | |
| 5M6213 | 12 PLUG-PIPE (1/4-18-THD) | 1 | |
| 3J7354 | 13 SEAL-O-RING | 1 | |
| 8M5248 | 14 SEAL-O-RING | 2 | |
| 9S8002 | 15 PLUG (7/16-20-THD) | 1 | |
| 4M6480 | 16 GASKET | 1 | |
| 0L2070 | 17 BOLT (3/8-16X2.25-IN) | 1 | |
| 8N1149 | 18 ELBOW | 1 | |
| 9S4185 | 19 PLUG (3/4-16-THD) | 1 | |
| 2W0157 | 20 TUBE AS-OIL DRAIN | 1 | |
| 4W1512 | 21 SUPPORT AS-PUMP | 1 | |
| 5H4279 | PLUG-CUP | 1 | |
| 8T6765 | PLUG-PIPE (1/4-18-THD) | 1 | |
| 0S1617 | 23 BOLT (5/16-18X0.75-IN) | 1 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9M4849 | 25 SEAL-O-RING | 1 |
